Overview
The Mitsubishi OSA17-060 is a rotary feedback device used with servo motors to provide position and speed feedback for motion control systems. Installed on the output shaft of a servo motor where accurate angular position and velocity information is required for closed-loop control, this encoder delivers reliable real-time positioning data to servo drives and motion controllers.
Key Features
- A/B quadrature outputs for position/speed feedback
- 60 pulses per revolution (P/R) or model variant
- 131,072 counts/rev resolution for high-precision motion capture
- Direct shaft coupling for servo motor installation
- Dependable feedback to servo drives and motion controllers for accurate trajectory control, synchronization, and speed regulation
- Programmable resolution for flexible system requirements
Technical Specifications
Encoder Type: Incremental or absolute (model dependent)
- Output Signals: A/B quadrature outputs for position/speed feedback
- Interface: Differential or single-ended output (model variant)
- Mounting: Direct coupled to servo motor shaft
- Frequency Response: High-speed pulse response for dynamic motion
- Protection Rating: Industrial environmental suitability
- Battery bit available for encoder data retention
Typical Applications
The Mitsubishi OSA17-060 encoder is used in industrial automation, robotics, CNC machines, packaging systems, conveyor indexing, and precision positioning applications where real-time position and speed feedback enhances motion control performance. Maintenance teams, system integrators, and OEMs use this encoder for replacement, retrofit, and system upgrades to ensure precise motion feedback and improved accuracy in automated equipment.
Compatibility & Replacements
Compatible With
- Mitsubishi servo motors with encoder input capability
- Mitsubishi HC and HF series servo drives
- Mitsubishi motion controllers and PLCs
- Systems requiring A/B quadrature feedback
- OSA17 can replace OSA14 and other encoder types when programmed accordingly, with dash number indicating programmed resolution
Replaces / Drop-In Replacement For
- OSA14 encoders (typically identified as OSA17-020)
- Original Mitsubishi OSA17-060 units requiring replacement
- System upgrades from lower-resolution encoders to OSA17 platform
Works With
- Mitsubishi servo amplifiers and drives
- Automation systems requiring rotational feedback
- CNC control systems and motion controllers
- Closed-loop motion control platforms
- Position and speed monitoring applications
