Overview
The Dodge 010603 Para-Flex PX70 Taper-Lock flange assembly is a precision-engineered power transmission component designed for flexible tire coupling systems. Built with sintered steel flanges, this Type H flange is pre-assembled and ready for immediate installation on shafts. The 1610 bushing size accommodates bore diameters from 0.5″ to 1.6875″ for flexible, close-coupled shaft connections.
Key Features
- Standard Taper-Lock® bushings — enables quick installation and removal without special tools
- Reversible flange design — supports both H and F style mounting across PX50-PX120 sizes
- Pre-assembled for rapid deployment — reduces installation time and simplifies field replacements
- Sintered steel construction — delivers durability and consistent torque transmission
- ATEX certified — meets international standards for hazardous area applications
- Elastomeric tire coupling compatibility — works seamlessly with Para-Flex flexible tire couplings
Technical Specifications
This flange assembly handles up to 2200 in-lb (247.7 N·m) of torque at maximum speed and supports 3.49 hp at 100 rpm. Operating temperature range spans -45°F to +180°F (-42.7°C to 82.2°C), making it suitable for diverse industrial environments. The 7.375″ outside diameter and 1″ length through bore integrate seamlessly with standard shaft spacing.
Typical Applications
- Industrial pump and fan coupling systems
- Compressor and motor shaft connections
- Machine tool drive trains requiring flexible alignment
- Chemical processing equipment with temperature cycling
- ATEX Zone 1 and Zone 2 hazardous location machinery
Compatibility & Replacements
Compatible With
- Dodge Para-Flex flexible tire couplings (PX70 series)
- Standard 1610 Taper-Lock® bushings
- Reversible H and F flange styles for mixed mounting
- Close-coupled shaft assemblies with 0–1.6875″ bore diameters
Replaces / Drop-In Replacement For
- Dodge PX70 TL FLG ASSY 1610 (OEM equivalent designation)
- Legacy Para-Flex flange assemblies requiring standard Taper-Lock engagement
Works With
- Dodge Para-Flex® flexible tire coupling family
- Standard mechanical power transmission systems
- Industrial equipment using elastomeric coupling technology
- ATEX-certified machinery and hazardous area applications
