Overview
The Allen-Bradley 194E-A25-1753 is a 25-amp 3-pole disconnect switch engineered for industrial load-switching applications. This IEC-rated switch delivers dependable ON/OFF control with a compact, open-style design ideal for panel mounting, distribution cabinets, and machine control systems. The 90° throw action provides quick power isolation and clear visible OFF position for safe maintenance and lockout/tagout (LOTO) procedures.
Key Features
- 25-amp rated capacity for motors and power distribution circuits
- 3-pole configuration handles 3-phase power systems
- 90° ON/OFF quick-break action with manual lever control
- Open enclosure style for base or DIN-rail mounting
- IEC load switch standard—international compliance ready
- Rated to 690 VAC maximum (11 kW @ 690 VAC, 7.5 kW @ 400 VAC)
Technical Specifications
- Current Rating: 25 amps
- Voltage Rating: 690 VAC (IEC standard)
- Poles: 3-pole (3P)
- Throw: 90°
- Operating Cycles: 200,000 mechanical
- Mounting: Base/DIN rail
- Operating Temperature: −25 to +60°C (storage −40 to +80°C)
- Terminals: Standard screw or field-selectable connectors
- Series: Allen-Bradley Bulletin 194E
- Certification: UL, CSA, CE, CCC, KC
Typical Applications
- 3-phase motor disconnection and load switching
- Power distribution and branch circuit isolation
- Equipment lockout/tagout (LOTO) control points
- Transformer switching in industrial facilities
- Machine tool and pump control circuits
- Panel-mounted manual load control
Compatibility & Replacements
Compatible With
- Allen-Bradley 194E series accessories and handle kits (Type G, Q, N actuators)
- DIN-rail and base-mounted industrial control panels
- Standard IEC distribution equipment and motor starters
- 3-phase industrial power systems (50/60 Hz)
Replaces / Drop-In Replacement For
- 194E-A25-1753 prior Series A units
- Other 25A 3-pole IEC load switches (verify interchangeability with system integrator)
Works With
- Industrial control systems with manual load-switching requirements
- Motor protection and control circuits
- Standard industrial electrical panels and distribution cabinets
- Lockout/tagout (LOTO) procedures and safety interlocks
