Overview
The Allen-Bradley 1485K-P3F5-R5 is a DeviceNet physical media cable assembly engineered for reliable connectivity in industrial automation applications. This 3-meter KwikLink cordset features a passive cable construction with PVC insulation and epoxy-coated zinc connectors. The cable is designed for drop-line and trunk connections in DeviceNet networks and is commonly used in factory automation, process control, and discrete manufacturing environments.
Key Features
- 3-meter flat media cable length for optimal reach in compact installations
- Micro connector configuration: right-angle male trunk end and straight female device end
- 5-pin standard connector design for DeviceNet protocol compliance
- PVC cable jacket with epoxy-coated zinc connectors for corrosion resistance
- 4 amp current rating suitable for sensor and I/O node connections
- Operating temperature range -20 to 80°C for industrial environments
Technical Specifications
- Cable Length: 3 meters
- Protocol: DeviceNet
- Connector Type: Micro 5-pin
- Trunk End: Right-angle male
- Device End: Straight female
- Current Rating: 4 Amp
- Insulation: PVC
- Connector Material: Epoxy-coated zinc
- Operating Temperature: -20 to 80°C
- Conductor Type: Multi-core
- Construction: KwikLink Cordset, standard passive cable
- Weight: 0.46 lbs
Typical Applications
- Discrete manufacturing and assembly line control systems
- Process automation networks using DeviceNet protocol
- Sensor and I/O module connectivity in factory environments
- Pneumatic and hydraulic system control networks
- Inline drop-line connections for distributed control architectures
- Retrofit and upgrade projects in existing DeviceNet installations
Compatibility & Replacements
Compatible With
- DeviceNet control networks and nodes
- Allen-Bradley CompactLogix, ControlLogix, and MicroLogix controllers with DeviceNet modules
- DeviceNet master devices and scanner modules
- Third-party DeviceNet-compliant industrial devices
- Discrete sensors, actuators, and I/O modules with DeviceNet adapters
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This cable is a standard KwikLink assembly; consult your system documentation for exact replacement specifications.
Works With
- DeviceNet protocol and networks
- Allen-Bradley RSLogix and Studio 5000 software environments
- EDS (Electronic Data Sheet) file configurations for DeviceNet devices
- Industrial automation control systems utilizing 5-pin micro connectors
