Overview
The GE 97F5502 is a polypropylene film motor run capacitor from General Electric’s GEM series, designed for permanent split-capacitor (PSC) motor applications. With a capacitance of 2µF and voltage rating of 370VAC at 50/60Hz, this snap-in terminal capacitor provides the efficiency and reliability required in HVAC systems, appliances, and light industrial equipment. The Dielektrol VI dielectric fluid and UL-recognized pressure-sensitive interrupter (PSI) offer built-in fault protection.
Key Features
- Capacitance: 2µF with ±10% tolerance
- Voltage Rating: 370VAC, 50/60Hz
- Terminal Type: Snap-in quick-connect blades (0.250″ x 0.031″)
- Dielectric: Dielektrol VI fluid with UL-recognized PSI protection
- Series: GEM polypropylene film capacitor
- Operating Life: 60,000 hours with 94% survival rate
- Leakage Current: 30µA maximum
Technical Specifications
- Capacitance Range: 2µF
- Capacitance Tolerance: ±10%
- Rated Voltage: 370VAC RMS sinusoidal
- Frequency: 50/60Hz
- Operating Temperature: −40°C to +70°C
- Storage Temperature: −40°C to +90°C
- Dissipation Factor: 0.1% maximum
- Case Material: Unpainted aluminum with tern plate steel cover
- Internal Protection: UL-recognized Pressure Sensitive Interrupter (PSI)
- Terminations: Combo terminal 0.250″ x 0.031″ quick-connect blades
- Available Fault Current (AFC): Up to 10,000 amperes
- Quantity: 3 units per lot
Typical Applications
The GE 97F5502 is widely used in permanent split-capacitor motor applications including:
- HVAC heating and cooling equipment
- Refrigeration and air conditioning units
- Fan motors and blower assemblies
- Appliances and business machines
- Office equipment and light industrial machinery
These capacitors improve motor efficiency and are suitable for either 50Hz or 60Hz systems, though not for applications with higher frequency harmonics.
Compatibility & Replacements
Compatible With
- Permanent split-capacitor (PSC) motors
- 50Hz and 60Hz single-phase AC systems
- HVAC and refrigeration compressor motors
- Fan and blower motor circuits
- Equipment with snap-in quick-connect terminals
Replaces / Drop-In Replacement For
The GE 97F5502 is the OEM part for GE motor run capacitor applications rated 2µF 370VAC. For verified compatible replacements with identical ratings, verify matching capacitance (2µF), voltage (370VAC minimum), frequency (50/60Hz), and snap-in terminal configuration with your system integrator before ordering.
Works With
- GE Genteq motor capacitors and compatible brands
- Standard 50/60Hz AC power distribution
- Quick-connect snap-in terminal wiring harnesses
- UL/CSA-certified HVAC and appliance control systems
