<h2>Overview</h2>
<p>The <strong>SMC CG5EN32TNSV-25</strong> is a compact double-acting air cylinder with a 32mm bore and stainless steel construction. Rated for maximum operating pressure of 145 PSI, this cylinder delivers reliable linear actuation in demanding industrial environments. The CG5-S (stainless) series features all external stainless steel components, making it ideal for applications exposed to moisture, coolant mist, and corrosive conditions.</p>
<h2>Key Features</h2>
<ul>
<li>Compact stainless steel design resists corrosion in wet and humid environments</li>
<li>Double-acting configuration for smooth extend and retract operations</li>
<li>External configuration reduces liquid pooling, extending cylinder life</li>
<li>Choice of gasket seal materials for specific application requirements</li>
<li>Standard mounting options for flexible installation</li>
</ul>
<h2>Technical Specifications</h2>
<ul>
<li><strong>Bore Size:</strong> 32mm</li>
<li><strong>Cylinder Type:</strong> Double-Acting, Single Rod</li>
<li><strong>Maximum Operating Pressure:</strong> 145 PSI (1.0 MPa)</li>
<li><strong>Construction Material:</strong> Stainless Steel (CG5-S Series)</li>
<li><strong>Seals:</strong> Configurable gasket materials</li>
<li><strong>Mounting:</strong> Available with multiple bracket options</li>
</ul>
<h2>Typical Applications</h2>
<ul>
<li>Food processing and beverage production equipment</li>
<li>Packaging machinery in wet environments</li>
<li>Automotive manufacturing with coolant exposure</li>
<li>Pharmaceutical and cleanroom equipment</li>
<li>Marine and offshore automation systems</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>SMC solenoid air valve systems (4/2, 5/2, 5/3 configurations)</li>
<li>Pneumatic control systems operating at 145 PSI or below</li>
<li>Standard ISO cylinder mounting brackets and adapters</li>
<li>Air line tubing sized for 32mm bore cylinders</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<p>The SMC CG5EN32TNSV-25 may replace other compact stainless cylinders in the CG5-S series with 32mm bore and 145 PSI rating. Verify exact stroke length and mounting configuration with your system integrator before ordering.</p>
<h3>Works With</h3>
<ul>
<li>SMC solenoid valve manifolds and pilot-operated controls</li>
<li>Pneumatic logic systems and proportional valve controllers</li>
<li>Speed control and flow regulation accessories</li>
<li>Standard compressed air networks and mobile equipment</li>
</ul>
