Overview
The Bimba CEF-01206-A pneumatic cylinder is a compact, double-acting actuator designed for space-constrained industrial applications. This cylinder converts compressed air energy into linear motion, making it ideal for manufacturing automation, machinery control, and motion-intensive processes where footprint matters. Bimba cylinders are manufactured in the United States and engineered for long service life with minimal maintenance requirements.
Key Features
- Double-acting design enables controlled extension and retraction
- Compact form factor optimized for space-limited installations
- Low-maintenance construction with sealed bearing surfaces
- Standard industrial pneumatic interface (threaded ports)
- Proven Bimba quality and reliability across thousands of deployed units
Technical Specifications
The CEF-01206-A is engineered to operate within standard industrial pneumatic pressure ranges, typically up to 250 PSI for Bimba Original Line cylinders. The compact design minimizes installation volume while maintaining effective force output for typical automation tasks. Exact bore size, rod diameter, stroke length, and porting configuration should be verified with the manufacturer or distributor before final system integration.
Typical Applications
- Automated manufacturing and assembly equipment
- Material handling and positioning systems
- Packaging machinery automation
- Machine tool control and indexing
- Fixture clamping and work-holding operations
- Conveyor and transfer line control
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems (ISO 4401 porting)
- Compressed air systems operating at 250 PSI maximum
- Industrial directional control valves (3/2, 4/2, 4/3 configurations)
- Pneumatic manifold assemblies
- Pressure regulators and pressure-relief valves
- Flow control valves and air preparation equipment
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Bimba manufactures multiple compact cylinder series; confirm that the CEF-01206-A meets your specific bore, stroke, and porting requirements.
Works With
- Standard ISO 4401 (formerly NFPA) pneumatic systems
- Electronic position-sensing switches (optional Bimba accessories)
- Pneumatic logic and control circuits
- PLC-based motion control systems with solenoid valve interfaces
- Industrial automation software integrating pneumatic subsystems
