Overview
The SMC MGF63-30 is a low-profile guide table cylinder from SMC’s MGF series, engineered for compact pneumatic automation applications. The MGF low profile guide table integrates a compact cylinder to a large diameter concentric guide sleeve to handle loads applied from any direction providing equal eccentric load resistance through 360°. The MGF63 variant delivers reliable motion control in space-constrained production environments.
Key Features
- Series MGF guide tables are low profile, compact cylinders which utilize a large concentric guiding sleeve to provide excellent eccentric load resistance
- Mounting is possible from 2 directions
- A built-in non-rotating mechanism prevents rotation of the table top
- T-slots are provided on 3 faces of the MGF body, allowing mounting of various brackets
- Optional auto switches can be mounted on 4 faces of the body
- Double-acting design with smooth, controlled pneumatic operation
Technical Specifications
The SMC MGF63-30 offers precise load handling across a range of operating speeds. When MGF63 is operated with a load mass 30 kg and 100 mm eccentric distance, the cylinder can be used at a maximum speed of 100 mm/s or less.
Typical Applications
- Precision positioning and material handling tables
- Industrial assembly and manufacturing automation
- Heavy-duty workholding fixtures
- Eccentric load applications requiring 360° load support
- Press and clamp systems requiring guided motion
- Automated conveyor and transfer systems
