Overview
The SMC CDM2E32-75AZ is a round-body pneumatic cylinder engineered for double-acting operation with compressed air. This single-rod, double-acting unit features a 32mm bore diameter and 75mm stroke, making it ideal for automation systems requiring compact linear motion control. SMC CDM2E32-75AZ cylinders are widely used in manufacturing, assembly, and material handling equipment where reliability and consistent performance are critical.
Key Features
- Double-acting, single-rod design for forward and reverse air pressure control
- 32mm bore diameter with 75mm standard stroke length
- Integral clevis-style mounting for easy installation
- Rubber cushion bumpers for smooth end-of-stroke deceleration
- Male rod-end thread configuration (standard)
- Rc-threaded ports for standard pneumatic line connections
- Compact round body design reduces footprint in tight spaces
Technical Specifications
The SMC CDM2E32-75AZ meets industry standards for pneumatic actuation and is compatible with standard compressed-air systems operating at pressures up to 1.0 MPa (typical industrial range). Consult the official SMC datasheet or your system design documentation for exact pressure ratings and flow requirements.
Typical Applications
- Automated assembly and manufacturing machinery
- Packaging and material handling equipment
- Machine tool fixtures and workholding systems
- Pressing, clamping, and positioning tasks
- Robotic end-effectors and gripper systems
- General industrial automation and pneumatic control circuits
Compatibility & Replacements
Compatible With
- Standard compressed air supply systems (0.5–1.0 MPa operating range)
- Pneumatic manifold blocks with Rc-threaded port connections
- FRL (Filter-Regulator-Lubricator) assemblies for air preparation
- Pneumatic solenoid valves and proportional control systems
- Industrial PLC and automation controllers
- Standard pneumatic tubing and fittings (Rc thread)
Replaces / Drop-In Replacement For
- SMC CDM2E32-75A (legacy predecessor model)
- Other CDM2 Series cylinders with matching 32mm bore and 75mm stroke specifications
- Verify exact compatibility with your system integrator before ordering, as port orientation and mounting style variations exist within the CDM2 family
Works With
- SMC pneumatic valve systems and proportional controllers
- FESTO, Parker, Bosch Rexroth, and other third-party pneumatic components (with adapter verification)
- Open-architecture automation systems using standard pneumatic logic
- Industry-standard pneumatic communication protocols and manual valve controls
