Overview
The Allen-Bradley 1201-HASP human interface module delivers programmable control and intuitive operator interface functionality for SCANport-compatible adjustable frequency drives. Designed as a snap-in cradle-mount peripheral, this terminal combines a built-in LCD display with straightforward navigation keys and speed control, enabling technicians and engineers to program, monitor, and troubleshoot drive parameters in the field.
Key Features
- Integrated LCD screen with five functional keys for menu-driven control
- Directional up/down speed control button for real-time parameter adjustment
- Snap-in cradle mount design simplifies installation and removal
- NEMA Type 1 / IP30 rated enclosure for dust and indirect water splash protection
- Operates reliably at 80% non-condensing humidity
- Compact form factor for integration into control cabinets and operator stations
Technical Specifications
- Input Voltage: 12 VDC
- Power Consumption: 0.11 A (approximately)
- Enclosure Rating: NEMA Type 1 / IP30
- Operating Temperature Range: 0°C to 40°C
- Operating Humidity: Up to 80% non-condensing
- Altitude Rating: Up to 1000 meters above mean sea level
- Display: Liquid Crystal Display (LCD)
- Control Interface: Five function keys + up/down speed control
- Mounting: Snap-in cradle mount
- Communication Port: SCANport-compatible
Typical Applications
The 1201-HASP is commonly deployed in:
- Adjustable frequency drive (AFD) configuration and commissioning
- Motor speed control and parameter adjustment in production environments
- On-site troubleshooting and fault diagnostics for SCANport drives
- Drive programming for FORCE and standard 1300-series adjustable frequency controllers
- Operator interface integration in industrial automation panels and control enclosures
Compatibility & Replacements
The Allen-Bradley 1201-HASP /A integrates with SCANport-compatible drives including the 1305, 1335, 1394, and 1557 series. The Series A revision is commonly used as an upgrade path from earlier 1201 programmer variants and remains a standard hand-held programming solution. While the manufacturer has released later graphic programming terminal models (such as the 1201 GPT), the 1201-HASP remains available through authorized and surplus distributors for field retrofits and replacement scenarios. Technicians should verify cradle compatibility and SCANport port availability on their target drive before ordering.
