Overview
The Telemecanique ZB6-AW9 is an illuminated push button operator designed for industrial control panels and machinery. Part of Schneider Electric’s Harmony ZB6 series, this 16mm momentary switch combines compact form factor with bright LED illumination for dependable operator feedback and control. Built for demanding industrial environments, the ZB6-AW9 delivers straightforward push-to-activate functionality with integrated lighting to enhance visibility in low-light control rooms and machinery enclosures.
Key Features
- Momentary (retractive) operation—returns to normal position when released
- Integrated illumination for enhanced operator visibility and safety feedback
- 16mm compact push button head fits standard panel cutouts
- Suitable for AC and DC control circuits with appropriate contact blocks
- Robust construction for heavy industrial duty cycle
- Modular design allows flexible contact block and mounting base combinations
Technical Specifications
The ZB6-AW9 features a durable push button operator compatible with Harmony ZB6 contact blocks and light modules. Available contact configurations support both DC and AC switching applications. Operating temperature range supports standard industrial environments from 0°C to 55°C. The 16mm head size accommodates standard panel mount installations.
Typical Applications
- Machine tool control and start/stop commands
- Production line operator interfaces
- Process equipment panel-mounted control
- Emergency lighting circuits with momentary functions
- Assembly and packaging machinery
Compatibility & Replacements
The ZB6-AW9 uses standard Harmony ZB6 modular contact blocks and light modules, enabling quick field reconfiguration without replacing the entire operator. Direct replacement for OEM Telemecanique ZB6 illuminated push button assemblies. Compatible with standard 16mm push button mounting bases and brackets. When substituting or upgrading, verify contact block specifications (voltage rating, contact type, and load rating) to match your application’s electrical requirements.
