Overview
The Telemecanique XAL-D/K…H7 emergency stop pushbutton is a pre-assembled control station enclosure built for safety-critical industrial applications. This unit combines a robust mounting base with integrated pushbutton controls, offering reliable emergency stopping for manufacturing equipment, processing machinery, and automated systems. The XAL series represents a proven platform trusted across process automation and discrete manufacturing environments.
Key Features
- Pre-assembled control station enclosure—no field assembly required
- Red emergency stop button for immediate visual identification and quick actuation
- Mechanical latching design ensures positive action under fault conditions
- Complies with EN/IEC 60204-1, EN/ISO 13850, and EN/IEC 60947-5-5 safety standards
- Meets Machinery Directive 2006/42/EC requirements
- Compatible with XB5 series 22 mm modular pushbutton components
Technical Specifications
- Manufacturer: Telemecanique (Square D/Schneider Electric)
- Model: XAL-D/K…H7
- Button Type: Pushbutton enclosure with red mushroom head
- Control Station Type: Pre-assembled XAL station
- Compatible Components: XB5 22 mm range pushbuttons
- Mounting: Surface or panel mount
- Safety Standards: EN/IEC 60204-1, EN/ISO 13850, EN/IEC 60947-5-5, Machinery Directive 2006/42/EC
- Contact Configuration: Electrical contacts configurable via contact blocks (sold separately)
- Condition: New, open box
Typical Applications
- Factory floor machinery and equipment emergency shutdown
- Production line safety interlocks
- Press and stamping machine control stations
- Conveyor system emergency stop stations
- Packaging and assembly machine safety circuits
- Industrial automation and PLC-controlled equipment
Compatibility & Replacements
The XAL-D/K…H7 is part of the Telemecanique Harmony control station line and works alongside other components in the XAL and XB5 ecosystem. The enclosure accepts standard 22 mm modular pushbutton heads and contact blocks, allowing for flexible field customization. As a discontinued or legacy part, direct OEM replacements include the newer Harmony XB5 or M22 modular systems from Schneider Electric. For immediate compatibility in existing systems, original Telemecanique XAL housings and contact block combinations are preferred.
