Overview
The Allen-Bradley 800H-NP14 /X is a NEMA 7/9 classified enclosure cover for push button applications in hazardous location installations. Part of the 800H Bulletin series, this cover is designed to protect push button operators and stations in Class II and Class III hazardous dust and fiber locations. The Series X designation indicates the industrial-grade construction suitable for demanding field environments.
Key Features
- NEMA 7/9 certification for Class II (combustible dust) and Class III (combustible fiber) hazardous locations
- Corrosion-resistant design with excellent sealing properties
- Compatible with Bulletin 800H push button operator bases and stations
- Robust Series X construction for extended service life
- Simple field installation on existing 800H stations
Technical Specifications
- Part Number: 800H-NP14 /X
- Series: Bulletin 800H, Series X
- NEMA Classification: Type 7/9
- Hazardous Location Classes: Class II (Groups E, F, G) and Class III
- Material: Industrial-grade enclosure material
- Mounting: Field-installable on compatible 800H stations and bases
- Lifecycle Status: Active
Typical Applications
- Grain processing facilities and agricultural applications (Class II, Group G)
- Metal powder manufacturing and handling (Class II, Groups E and F)
- Textile mills and fiber handling operations (Class III)
- Coal preparation and processing plants
- Chemical manufacturing with dust hazards
- Emergency stop and control stations in hazardous environments
Compatibility & Replacements
The 800H-NP14 /X cover is designed for use with Bulletin 800H push button bases and complete stations. Installation requires compatibility with the station base design. For alternative cover options or to verify compatibility with your specific 800H base configuration, consult Rockwell Automation technical documentation or contact an authorized Allen-Bradley distributor. The /X suffix denotes Series X specification.
