Overview
The SMC VV5Q11-08C6FU0-NS-X50US is a base-mounted pneumatic solenoid valve manifold designed for multi-station valve integration in industrial automation systems. This 8-station assembly includes four VQ1301N-51 and four VQ1201N-51 solenoid-controlled directional control valves, providing centralized control for pneumatic circuits. The manifold delivers consistent high-speed operation and stable response times, making it suitable for equipment requiring frequent valve actuation and long service life.
Key Features
- 8-station valve manifold with integrated solenoid valve block configuration
- Pre-assembled with VQ1301N-51 (4x) and VQ1201N-51 (4x) directional control valves
- Rapid solenoid response time for high-speed pneumatic control
- Innovative mounting design allows valve replacement without full manifold disassembly
- One-touch fittings reduce piping time and installation labor
- Compact base-mounted form factor for space-constrained installations
Technical Specifications
The manifold accepts standard SMC VQ series pneumatic control valves. System configuration features eight independent valve stations supporting dual 4/5-port solenoid valve operation. Built-in cavity design accommodates pilot-operated and direct-acting solenoid cartridges. Pressure-rated cavities support industrial pneumatic system pressures typical to compressed air automation.
Typical Applications
- Multi-axis pneumatic actuator control in assembly lines and transfer systems
- High-frequency solenoid valve switching for robotic end-effector operation
- Centralized pneumatic logic control in packaging and material handling equipment
- OEM pneumatic system integration requiring compact manifold footprint
- Process automation demanding consistent valve response and cycle reliability
Compatibility & Replacements
Compatible With
- SMC VQ1301N solenoid directional control valves
- SMC VQ1201N solenoid directional control valves
- Standard industrial compressed air systems (4–8 bar typical operating range)
- SMC manifold-mounted solenoid coil assemblies and pilot valve modules
- 24 VDC and AC solenoid coil options for valve actuation
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering to confirm direct replacement applicability with your existing 8-station valve manifold configuration.
Works With
- SMC VQ series pneumatic directional control valves
- Pneumatic logic control circuits and relay-based automation systems
- PLC-based solenoid valve control via standard 24 VDC I/O modules
- Industrial compressed air infrastructure with standard ISO cavity configurations
