Overview
The MAC 46A-AA1-JDE0-1KA is a 4-way directional control solenoid valve from MAC Valves’ 46 Series, designed for inline installation in industrial automation and motion control systems. This valve provides precise fluid routing for pneumatic, hydraulic, and motion applications requiring reliable single-solenoid operation.
Key Features
- 4-way, 2-position directional control solenoid valve
- Single solenoid with internal pilot operation for responsive switching
- Compact inline design suitable for space-constrained installations
- Fast, consistent response times with high shifting forces
- Short stroke solenoid with oval armature and balanced poppet design
- High flow capacity in minimal package footprint
Technical Specifications
The valve operates on 24 VDC with 1.8 watts power consumption and includes a 9.4 mm DIN connector (male). Flow coefficient (Cv) is 0.15, and the valve features 1/8″ NPT port configuration.
Typical Applications
- Industrial automation and motion control systems
- Pneumatic actuator circuits requiring directional control
- Hydraulic equipment and machinery
- Pump control and fluid handling systems
- Manufacturing and processing equipment
Compatibility & Replacements
Compatible With
- 24 VDC power supplies (1.8W minimum)
- 9.4 mm DIN connector male interface
- 1/8″ NPT port configurations
- Industrial control systems using MAC 46 Series valves
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering. The MAC 46 Series includes variant configurations; confirm exact replacement compatibility with original system documentation.
Works With
- 24 VDC control circuits
- PLC and motion control systems
- Pneumatic and hydraulic manifold systems
- Industrial automation platforms using directional valve controls
