Overview
The MAC 46A-AA1-JDE0-1KA solenoid valve is a compact 4-way, 2-position directional control valve from MAC Valves’ proven 46 Series lineup. Designed as a 4-way, single solenoid, internal pilot, 2-position solenoid valve operating at 24VDC, this valve delivers consistent switching performance in space-constrained pneumatic control applications. Features include a short stroke solenoid with oval armature, a balanced poppet and conical seats, providing high shifting forces, fast response times, high flow in a small package and long life.
Key Features
- 4-way, 2-position directional control configuration
- Internal pilot solenoid operation for reliable actuation
- Compact inline valve design, 1.8-watt coil power consumption
- Flow coefficient (Cv): 0.2 for optimized pneumatic circuits
- DIN connector, male—standard industrial interface
- Fast response time with consistent switching performance
- Suitable for pneumatic automation, material handling, and press control applications
Technical Specifications
- Valve Type: 4-Way, 2-Position Directional Control
- Series: MAC 46 Series
- Port Size: 1/8 inch NPT
- Voltage: 24VDC
- Coil Power: 1.8 watts
- Flow Coefficient (Cv): 0.2
- Actuation Method: Single solenoid, internal pilot
- Connector Type: 9.4 mm DIN connector, male only
- Response Time: Fast, consistent switching
- Operating Principle: Balanced poppet design with conical seats
Typical Applications
- Pneumatic directional control in automated manufacturing equipment
- Press and clamp control systems
- Material handling and conveyor automation
- Industrial machinery air switching circuits
- Low-power solenoid applications requiring compact form factor
Compatibility & Replacements
Compatible With
- Standard 24VDC control systems
- Pneumatic circuits with 1/8 inch NPT port infrastructure
- DIN connector interfaces and wiring standards
- MAC Valves manifold systems and accessories
- Industrial PLC and automation control panels
Replaces / Drop-In Replacement For
The MAC 46A-AA1-JDE0-1KA directly replaces other MAC 46A series inline valves with matching port sizes and 24VDC specifications. Verify compatibility with your system integrator before ordering to ensure proper voltage, connector, and port configuration match.
Works With
- MAC 46 Series valve family and accessories
- Pneumatic hose and fitting systems (1/8 NPT compatible)
- Industrial relay logic and PLC-based control systems
- 24VDC solenoid power supplies and control modules
- DIN-connector wiring harnesses and junction boxes
