Overview
The SMC SYJ514M-5DZ-01N is a 3-port pilot-operated solenoid valve from SMC’s proven SYJ500 series. This compact unit delivers reliable pneumatic control with a distinctive low-power solenoid architecture that minimizes heat generation and operating costs. The used condition unit remains fully functional and represents excellent value for retrofit, maintenance, and system expansion applications in industrial automation and fluid power systems.
Key Features
- Low-Power Design: 0.5W pilot solenoid reduces thermal load and enables direct PLC relay control without additional switching components
- Compact Form Factor: Space-efficient 3-port configuration for manifold mounting or single-valve installation
- 24 VDC Operation: Standard industrial voltage with DIN terminal connector and manual override
- Rubber Seal Construction: Durable sealing material suitable for compressed air and compatible gases
- Integrated Protection: Light and surge suppression available on electrical connector variants
Technical Specifications
Typical Applications
The SYJ514M-5DZ-01N serves pneumatic automation systems including:
- Machine tool positioning and clamping circuits
- Automated assembly and material handling equipment
- Process control valve banks and pilot-stage components
- Manifold-based control systems requiring compact footprint
- Retrofit projects where space and power consumption are critical
Compatibility & Replacements
Compatible With
- SMC sub-plates and manifold base systems
- Standard pneumatic circuits operating 0–10 bar (0–145 psi)
- Industrial PLC and relay logic control systems
- Compressed air and inert gas applications
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Other SYJ514M variants with different electrical terminations (e.g., SYJ514M-5LZ, SYJ514M-5WOU) may use the same cavity and solenoid, but electrical and manifold mounting must be confirmed.
Works With
- DIN 43650 connectors and manual controls
- SMC SYJ-series manifolds and accessory sub-plates
- Pneumatic circuit design software compatible with ISO 1219-1 symbols
- Standard 24 VDC industrial control relays and PLC outputs
