Overview
The SMC CDG1TA50-65 pneumatic air cylinder is a compact, double-acting actuator engineered for industrial automation applications. With a 50mm bore diameter and 65mm stroke length, this unit delivers predictable force output at 145 PSI operating pressure. The CDG1TA series combines space-efficient design with robust construction, making it ideal for material handling, assembly machinery, clamping systems, and process control.
Key Features
- Compact double-acting design reduces footprint in confined spaces
- 50mm bore with 65mm stroke for precise linear motion control
- Rated for 145 PSI maximum operating pressure
- Standard port and mounting configurations enable straightforward integration
- Durable construction with corrosion-resistant seals for extended service life
- Compatible with standard pneumatic control systems and solenoid valve stations
Technical Specifications
Cylinder Type: Double Acting, Single Rod
Bore Diameter: 50mm
Stroke Length: 65mm
Operating Pressure: 145 PSI (10 bar)
Port Configuration: ISO 4401 (CETOP) or equivalent
Mounting Style: Standard base (foot or flange options available)
Construction Material: Aluminum alloy cylinder body with steel rod
Seals: NBR standard (compatible with mineral oil lubrication)
Typical Applications
- Industrial machinery clamping and workholding
- Automated assembly and transfer systems
- Material handling and positioning
- Machine tool controls and punch presses
- Process automation and packaging equipment
- Pneumatic press and stamping operations
Compatibility & Replacements
Compatible With
- SMC pneumatic solenoid valve manifolds and distribution blocks
- SMC speed controllers (flow control valves)
- Standard 24 VDC and 120 VAC solenoid valve systems
- ISO 4401 (CETOP) compatible valve stations
- SMC auto switch detection systems for end-of-stroke signaling
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Common predecessor models in the SMC compact cylinder line may have similar mounting interfaces; however, exact model substitution should be confirmed with part number cross-reference documentation.
Works With
- Pneumatic pressure regulators and filter-regulator units
- Air cushioning systems for shock absorption
- Pneumatic logic and control circuitry
- Industrial PLC and motion control systems (via solenoid pilot control)
- ISO 4401 valve manifold platforms
