Overview
The SMC CP95SDB50-315 is a double-rod pneumatic cylinder engineered for high-performance applications requiring balanced force distribution and compact installation. With a 50mm bore diameter, 315mm stroke length, and maximum pressure rating of 145PSI, this cylinder combines robust construction with precision manufacturing typical of SMC’s automation-grade pneumatic products.
Key Features
- Double-rod design provides balanced force output on both extension and retraction
- 145PSI maximum operating pressure for reliable industrial duty cycles
- 50mm bore delivers adequate flow capacity for medium-to-high speed operations
- 315mm stroke accommodates moderate travel distances in compact machine layouts
- Designed to VDMA profile cylinder specifications for compatibility with standard mounting systems
- Durable construction suitable for repetitive cycling and varied industrial environments
Technical Specifications
The CP95SDB50-315 features proven SMC engineering with standard pneumatic cylinder dimensions and mounting options. This unit is rated for continuous operation at pressures up to 145PSI and is compatible with compressed air supply systems operating between typical industrial ranges.
Typical Applications
- Machine tool automation and CNC equipment clamping
- Assembly line positioning and transfer systems
- Industrial press applications requiring balanced force control
- Manufacturing equipment requiring medium-stroke actuation
- Automated material handling and positioning systems
Compatibility & Replacements
Compatible With
- SMC pneumatic valve systems and control manifolds
- Standard pneumatic pressure regulators and filter-regulators
- Industrial compressed air systems operating at 145PSI or below
- VDMA-standard mounting and bracket systems
- Pneumatic automation control systems and PLC-based controls
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or engineering team before ordering. SMC double-rod cylinders may have equivalent models in different series—consult technical documentation for specific cross-references.
Works With
- SMC solenoid valve control systems
- Industrial pneumatic manifold blocks and pilot-operated controls
- Standard compressed air supply with moisture and contaminant removal
- Proportional and directional control valves for speed regulation
- Mechanical position sensors and pneumatic end-of-stroke cushioning
