Overview
The Siemens 3RV1011-1GA10 is a molded case motor protection circuit breaker (MPCB) part of the SIRIUS 3RV1 series. This Class 10 device provides automatic protection for three-phase AC motors against overload and short-circuit faults. With screw terminals and a manual on/off rotary handle for easy tripping, it is designed for demanding industrial environments where reliable motor protection is essential.
Key Features
- Motor Protection Class 10 with adjustable thermal release (4.5–6.3 A) and magnetic release (82 A)
- Compact Size S00 form factor for tight DIN rail installations
- Rated for 220–690 VAC, 50/60 Hz operation
- Screw terminals for secure, corrosion-resistant connections
- Manual on/off rotary dial control for intuitive load setting and emergency shutdown
- Standard switching capacity per IEC 60947-4-1
Technical Specifications
- Device Type: Molded Case Circuit Breaker (MPCB)
- Series: SIRIUS 3RV1
- Frame Size: S00
- Rated Current Range: 4.5–6.3 A (Class 10)
- Thermal Release: Adjustable 4.5–6.3 A
- Magnetic Release: 82 A (short-circuit protection)
- Voltage Rating: 220–690 VAC, 50/60 Hz
- Power Rating: 2.2 kW @ 690 VAC
- Terminal Type: Screw
- Mounting: DIN rail
- Switching Capacity: Standard (per IEC 60947-4-1)
Typical Applications
The 3RV1011-1GA10 is commonly deployed in:
- Industrial motor control centers and starter panels
- Three-phase AC motor starters and soft-start drive circuits
- Manufacturing and processing equipment requiring compact DIN rail protection
- HVAC systems and pump drives in 220–690 VAC installations
- OEM equipment integration where space is limited
Compatibility & Replacements
Compatible With
- Siemens SIRIUS control systems and motor starters
- Standard DIN rail mounting in EN 60715-compliant switchboards
- Three-phase 220–690 VAC power distribution and control circuits
- IEC 60947-4-1 compliant motor protection applications
- Manual and soft-start motor control architectures
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or controls engineer before ordering. The 3RV1011-1GA10 may be substituted for similar Siemens SIRIUS motor protection devices within the same frame size and Class 10 rating; however, tripping characteristics and terminal configurations must match your existing installation.
Works With
- Siemens soft-start and inverter drive systems
- Manual motor starters (IEC 60947-4-2)
- Three-phase contactor and relay control circuits
- Standard industrial electrical distribution and overcurrent protection schemes
