Overview
The PKD-CDA keypad control board (model 9370-00864-001) from Advanced Input Devices is a robust industrial HMI component engineered for integration into control panels, machine interfaces, and automation systems. This keypad brings together multiple control functions—joystick, rotary encoder, and pushbutton capabilities—in a single compact and ergonomic form factor, enabling operators to access critical machine commands with minimal training and spatial footprint. Designed for harsh industrial environments, the PKD-CDA delivers responsive tactile feedback and supports multi-color LED feedback for intuitive status indication and command confirmation.
Key Features
- 3-in-1 multifunction control knob combining joystick, rotary encoder, and pushbutton
- Configurable RGB backlight and LED indicators for status feedback
- Compact, ergonomic design ideal for confined panel spaces
- Sealed design with high protection rating for industrial environments
- CANopen and J1939 protocol support for seamless system communication
- Customizable laser-etched icons and anodized knob options
Technical Specifications
- Model: PKD-CDA
- Part Number: 9370-00864-001
- Manufacturer: Advanced Input Devices
- Product Type: Keypad Control Board / HMI Input Device
- Control Functions: Joystick, rotary encoder, pushbutton
- Communication Protocol: CANopen, J1939
- Operating Temperature Range: -40°C to +70°C
- Sealing Rating: IP67/IP69K
- Actuation Life: 3 million operations
- LED Options: Configurable RGB with multiple color rings
- Mounting Options: Vertical, horizontal, or symmetrical panel mounting
Typical Applications
- Machine tool and CNC control panel interfaces
- Vehicle and mobile equipment operator controls
- Construction equipment PRND function control
- Defense and e-mobility platform HMIs
- Off-road and outdoor machinery command input
- Confined-space panel applications requiring multi-function control
Compatibility & Replacements
Compatible With
- CANopen-based industrial control systems
- J1939 protocol networks
- Industrial PLCs with CAN communication modules
- Standard 24 VDC industrial control panels
- Multi-axis machine control applications
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Advanced Input Devices parts typically have OEM-specific variants; direct replacement should be confirmed against your original equipment documentation.
Works With
- CANopen communication protocol
- J1939 vehicle/heavy equipment protocol
- Standard industrial 24 VDC control circuits
- RGB LED control and feedback systems
- Custom firmware and configuration via manufacturer software
