<h2>Overview</h2>
<p>The <strong>MAN6710 LED 7-segment display</strong> is a compact, red light-emitting numeric display module designed for panel-mounted equipment readouts and control interfaces. This unit combines proven 7-segment LED technology with industry-standard pinouts, making it a reliable choice for industrial counters, timers, frequency displays, and temperature indicators. The MAN6710 operates as a common anode configuration, compatible with standard digital logic circuits and microcontroller-based systems.</p>
<h2>Key Features</h2>
<ul>
<li>Red LED segments for high-visibility display in industrial environments</li>
<li>Common anode configuration for straightforward logic integration</li>
<li>0.56-inch (14.2 mm) character height — compact form factor</li>
<li>Two-digit display supporting full numeric range (0–99)</li>
<li>DIP-compatible pinout with 15.24 mm (0.6 in.) lead spacing on 2.54 mm centers</li>
<li>Low power consumption suitable for battery-backed and continuous-duty applications</li>
</ul>
<h2>Technical Specifications</h2>
<p>The MAN6710 operates within tight electrical and optical parameters designed for dependable performance in demanding environments:</p>
<ul>
<li><strong>Forward Voltage:</strong> 2.0 V per segment</li>
<li><strong>Forward Current:</strong> 20 mA per segment (typical)</li>
<li><strong>Luminous Intensity:</strong> 0.42 mcd per segment</li>
<li><strong>Power Dissipation:</strong> 960 mW (all segments active)</li>
<li><strong>Display Type:</strong> Two digits, common anode, red LED</li>
<li><strong>Character Height:</strong> 0.56 inches (14.2 mm)</li>
<li><strong>Lead Pitch:</strong> 2.54 mm (0.1 inch) centers</li>
<li><strong>Connector Type:</strong> DIP leads, 15.24 mm (0.6 in.) lead length</li>
</ul>
<h2>Typical Applications</h2>
<p>The MAN6710 serves a wide range of industrial and commercial applications:</p>
<ul>
<li>Digital panel meters and gauges</li>
<li>Equipment counters (cycle counters, part counters)</li>
<li>Temperature and process displays</li>
<li>Frequency and RPM readouts</li>
<li>Test equipment and bench instrumentation</li>
<li>Control system operator interfaces</li>
<li>Retrofit and legacy system upgrades</li>
</ul>
<h2>Compatibility & Replacements</h2>
<h3>Compatible With</h3>
<ul>
<li>TTL and CMOS logic circuits</li>
<li>PLC discrete output modules (with appropriate current-limiting resistors)</li>
<li>Microcontroller GPIO ports (8-bit and 16-bit platforms)</li>
<li>7-segment decoder ICs (74LS47, 74LS48, 4511 CMOS variants)</li>
<li>Standard industrial control panels with 5V or 12V logic supply</li>
</ul>
<h3>Replaces / Drop-In Replacement For</h3>
<ul>
<li>General Instrument MAN6710 (all production variants)</li>
<li>Intersil ISL16113 (pin-compatible red display)</li>
<li>ON Semiconductor MAN series red 2-digit displays</li>
</ul>
<h3>Works With</h3>
<ul>
<li>7-segment decoder and driver software libraries</li>
<li>IEC 61131-3 ladder logic programs (via standard I/O modules)</li>
<li>Arduino, Raspberry Pi, and embedded Linux platforms</li>
<li>Standard breadboard and PCB prototyping layouts</li>
<li>CAM and CNC control systems requiring numeric feedback displays</li>
</ul>
