Overview
The Marshall V-R104DP-2C is a professional-grade 10.4-inch rack-mount LCD field monitor designed for broadcast, video production, and multimedia applications. This model includes the Award Winning Digital TFT-Megapixel system with 1.44 million pixels plus Hyper Process for interlace image motion compensation. As a discontinued model, this used unit represents a cost-effective option for operators seeking proven composite-based monitoring in field and studio environments.
Key Features
- Dual switch-selectable composite video inputs
- 10-bit digitization with 4×4 pixel interpolation and color space conversion to emulate CRT phosphor standards
- V-Mount battery adapter support with 4-pin XLR power jack
- Optical grade polycarbonate screen protection
- Standard EIA 19-inch rack mounting configuration
- 1.44 million pixel TFT display for professional color accuracy
Technical Specifications
The V-R104DP-2C delivers professional video monitoring in a compact form factor. Analog signals are digitized using a 10 bit process and images are scaled to fit on screen in high resolution using state-of-the-art LSI with 4×4 pixel interpolation and Match Color Conversion to emulate SMPTE-C phosphor of a CRT. The monitor is equipped with standard BNC connectors (75Ω rated) for composite video input and output connectivity.
Typical Applications
- Broadcast video production and switching
- Professional video editing and color grading reference monitoring
- Live event video production
- Studio and field recording operations
- Multimedia and AV system installations requiring rack-mounted monitoring
- Archive or replacement monitoring for legacy broadcast setups
Compatibility & Replacements
Compatible With
- Standard EIA 19-inch equipment racks
- Composite (CVBS) video sources
- V-Mount battery systems (via supplied adapter)
- AC and battery-powered field production setups
- Professional broadcast and AV workflows
Replaces / Drop-In Replacement For
As a discontinued model, the V-R104DP-2C is suitable for replacement or upgrade applications in existing Marshall monitor installations. Verify compatibility with your system integrator or broadcast engineer before ordering.
Works With
- Composite video outputs from cameras, switchers, and video servers
- Standard video distribution amplifiers and routers
- Broadcast and multimedia production software ecosystems
- External monitoring and recording devices via composite loop-through capability
