Overview
The Allen-Bradley 889D-F4AC-5 is a Series B DC Micro (M12) cordset designed for reliable field device connectivity in industrial automation and control systems. The 889D-F4AC-5 features a 4-pin straight female connector with a 5-meter yellow PVC jacket cable and free conductor ends, making it ideal for connecting proximity sensors, limit switches, photoelectric sensors, and other M12-compatible field devices to control systems and PLCs.
Key Features
- 4-pin female M12 connector, straight orientation with quick-disconnect capability
- 5-meter cable length with yellow PVC jacket for easy identification and routing
- Rated for 4 amp at 250V—suitable for low-power sensor applications
- 22 AWG conductors in multi-core unshielded design
- Epoxy-coated zinc coupling nut with gold over nickel plated brass contacts for corrosion resistance
- Oil-resistant PUR housing for durability in harsh environments
- Color Code A wiring standard for compatibility with standardized industrial sensor systems
Technical Specifications
- Connector Type: M12 Female (Bus) Straight
- Pin Configuration: 4-pin
- Cable Length: 5 meter (16.4 feet)
- Wire Size: 22 AWG
- Current Rating: 4 Amp
- Voltage Rating: 250V
- Cable Type: Multi-core, unshielded PVC
- Jacket Color: Yellow
- Coupling Material: Epoxy-coated zinc with gold over nickel plated brass contacts
- Housing: Oil-resistant molded PUR
- Termination: Female bus connector with free conductor end
- Standard: Color Code A (IEC 61076-2-109)
- Series: B
- Condition: New in Box
Typical Applications
The Allen-Bradley 889D-F4AC-5 cordset is widely used in industrial automation environments where reliable sensor connectivity is critical:
- Proximity sensor connections to industrial controllers and safety systems
- Limit switch and photoelectric sensor field wiring
- Factory automation and assembly line control systems
- Machine tool connectivity and motion control applications
- Packaging and material handling equipment integration
- General industrial automation and process control installations
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix and ControlLogix programmable controllers
- Rockwell Automation CompactGuardian and GuardLogix safety systems
- Any M12 female connector-based industrial sensor or field device
- Standard IEC 61076-2-109 Color Code A wiring systems
- Industrial sensor networks using DC Micro (M12) connectors
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 889D-F4AC-5 is a Series B model with straight female connectors and free conductor ends. Other Allen-Bradley 889 series cordsets with different connector types (such as 889D-F4ACDM-5 with male straight connector on the other end) are not direct substitutes.
Works With
- Allen-Bradley industrial sensors and field devices with M12 female connectors
- Rockwell CompactLogix, ControlLogix, and GuardLogix input modules
- Standard DC Micro (M12) sensor ecosystems across multiple vendors
- Industrial networks using IEC 61076-2-109 connector standards
