Overview
The C014339 006AKAC-0003 coaxial cable is an RF pigtail assembly that connects SMA RA (right-angle) female to BNC Male connectors. This configuration is commonly used in radio communication equipment, test instrumentation, and RF systems where space constraints or cable routing require right-angle connector geometry. The impedance-matched design minimizes reflections and signal loss across RF frequencies.
Key Features
- SMA RA (right-angle) to BNC Male connector configuration
- Impedance-matched for minimal signal loss and VSWR reflections
- Compact pigtail design for flexible cable routing
- Suitable for 50-ohm RF applications
- Durable coaxial construction with strain relief
Technical Specifications
Exact specifications for this unbranded unit should be confirmed with the seller before ordering. Standard SMA-to-BNC coaxial pigtails typically feature:
- Impedance: 50 ohms (standard RF)
- Connector Type: SMA RA (female) to BNC (male)
- Frequency Range: DC to several GHz (varies by cable type)
- Cable Construction: Military-grade or equivalent coaxial shielding
- Operating Temperature: Typically −40°C to +85°C
Typical Applications
- Amateur and professional radio communication systems
- RF test equipment and instrumentation
- Antenna feed lines and feedthrough connections
- Signal amplifiers and distribution equipment
- Wireless transmission and reception circuits
Compatibility & Replacements
Compatible With
- RF equipment with SMA RA female connector ports
- RF equipment with standard BNC male connector ports
- 50-ohm impedance RF systems
- Radio communication transceivers and antennas
- Test and measurement instruments (spectrum analyzers, RF generators)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or original equipment documentation before ordering. Generic SMA RA to BNC male coaxial pigtails from various manufacturers share the same connector types and may be compatible depending on cable length, impedance, and frequency range requirements.
Works With
- Standard 50-ohm RF connector systems
- Amateur radio equipment (HF, VHF, UHF bands)
- Cellular and wireless communication systems
- Laboratory RF measurement equipment
