Overview
Allen-Bradley 700-HK36Z24 relays are 24V DC general purpose slim line relays engineered for high-density isolation and interposing applications. The 700-HK series features a compact ice-cube form factor with quick-connect terminations, making these units drop-in solutions for existing control panels without major rewiring. This lot includes 5 units, all new in box.
Key Features
- Single Pole Double Throw (SPDT) contact configuration with 16-amp contact rating
- 24V DC coil voltage for standard industrial power sources
- Slim line ice-cube design with 5-blade quick-connect terminations—no soldering required
- Jumper system integrated into the 700-HK design to reduce wiring complexity and maintenance costs
- Compact dimensions (29 mm width × 39.3 mm height × 12.4 mm depth) for space-constrained control panels
- Rated electrical life cycle of at least 6,000 operations
- Silver nickel (AgNi) contact material for excellent conductivity and arcing resistance
Technical Specifications
The 700-HK36Z24 meets UL, cULus, and CSA certification standards (File No. 75088), ensuring compliance with North American electrical safety codes. Operating temperature range is -40°C to 40°C, with IP20 degree of protection against dust and solid objects. The relay is tested for shock and vibration resistance for reliable performance in demanding industrial environments.
Typical Applications
- Industrial control panel isolation circuits
- PLC and automated machinery interposing relay networks
- Motor starter and contactor control feedback logic
- Safety interlock and emergency stop circuits
- High-density compact enclosure switching
- OEM equipment retrofits and upgrades
Compatibility & Replacements
Compatible With
- Allen-Bradley Bulletin 700 relay sockets (standard ice-cube base)
- Rockwell Automation control systems and PLCs
- 24V DC industrial power distribution schemes
- Standard industrial control panel enclosures
- Any OEM equipment using 24V DC slim line relays
Replaces / Drop-In Replacement For
- 700-HK36Z24 (base unit—exact model match)
- 700-HK general purpose slim line relay series
- Legacy interposing relays with equivalent 24V DC / 16A SPDT ratings
Works With
- Allen-Bradley relay sockets (NLDX, NLDX7, NLCX8 series)
- Quick-connect wiring harnesses and DIN-rail socket assemblies
- Standard industrial terminal blocks and panel-mount hardware
- 24V DC control circuits in Studio 5000 and FactoryTalk-based systems
