Overview
The SMC VV5Q11-07-DAL01092 is a precision solenoid valve manifold from the proven VQ1000 series, engineered for demanding pneumatic automation systems. This base-mounted manifold delivers reliable directional control with space-efficient design and modular construction, making it suitable for industrial machinery, process automation, and fluid power systems that require frequent cycling and stable response characteristics.
Key Features
- Plug-in Construction: Innovative mounting design allows individual valves to be changed without disassembling the entire manifold
- Space-Saving Layout: One-side solenoid and fittings positioning enables three-directional mounting flexibility
- Reduced Assembly Labor: One-clamp structure eliminates fastening hardware and streamlines recombination procedures
- High-Speed Operation: VQ valve technology supports frequent cycling with stable response time and extended service life
- One-Touch Fittings: Integrated fittings minimize piping requirements and installation time
- Flexible Wiring Options: Multiple electrical connection methods to accommodate various control schemes
Technical Specifications
Details such as port sizing, operating pressure range, flow capacity, and electrical ratings should be verified against the manufacturer’s current datasheet or your system integrator, as variant specifications may vary by configuration code.
Typical Applications
- Automated assembly and transfer machinery
- Industrial packaging and labeling equipment
- CNC machine tool pneumatic systems
- Robotic end-of-arm tooling controls
- Process automation valve banks
- Hydraulic and fluid power distribution systems
Compatibility & Replacements
Compatible With
- SMC VQ series pneumatic solenoid valves (4 and 5 port directional control)
- Standard pneumatic port fittings and one-touch connectors
- 24 VDC and 110/220 VAC solenoid coil options
- Pneumatic systems operating at manifold-rated pressures
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The VV5Q11-07-DAL01092 is designed as a direct replacement within the SMC VQ1000 series family; however, exact model substitution should be confirmed based on your specific port configuration, solenoid voltage, and connection type requirements.
Works With
- SMC VQ solenoid valve cartridges (all compatible pressure ratings)
- Back pressure check valve options for load-holding applications
- Dual flow fitting kits for flow rate adjustment
- D-sub connectors, flat ribbon cable, and lead wire electrical connections
- EX510 gateway systems and serial transmission control networks
