Overview
The SMC VP542R-5DZ1-03A-X505 is a 3-port solenoid valve from SMC’s VP300/VP500/VP700 series, designed for reliable pneumatic automation and motion control. This pilot-operated, poppet-type valve combines durable construction with efficient power consumption, making it suitable for industrial applications requiring precise directional control and flow management.
Key Features
- 3-port pilot-operated poppet-type design for smooth, responsive valve action
- Body-ported single unit configuration for flexible mounting and integration
- Reduced power consumption: 0.55W with power saving circuit, 1.55W standard operation
- Rubber seal construction for reliable sealing in diverse operating environments
- High flow capacity across the VP500 series range
- RoHS compliant for environmental and regulatory compliance
Technical Specifications
The following specifications apply to the VP542R-5DZ1-03A-X505 and related VP500 series models:
- Port Configuration: 3-port
- Valve Type: Pilot-operated poppet
- Mounting Style: Body-ported, single unit
- Seal Material: Rubber
- Power Consumption (Standard): 1.55W
- Power Consumption (Power Saving): 0.55W
- Solenoid Options: Available with AC or DC coils
- RoHS Compliance: Yes
Typical Applications
The SMC VP542R-5DZ1-03A-X505 is commonly used in:
- Pneumatic automation and motion control systems
- Industrial machinery directional control circuits
- Selector and divider valve applications
- Equipment requiring precise flow and pressure management
- Systems where low power consumption is critical
Compatibility & Replacements
Compatible With
- SMC pneumatic control systems and manifolds
- Standard pneumatic airlines and fittings (body-ported configuration)
- DC and AC solenoid coil options for flexible power integration
- Industrial automation frameworks using 3-port valve architecture
Replaces / Drop-In Replacement For
Verify with your system integrator or controls engineer for exact interchangeability with predecessor models or competing brands. Common SMC VP500 series variants may share compatible body porting, but coil and seal specifications should be confirmed.
Works With
- SMC pneumatic components and valve manifolds
- Industrial PLC and motion control systems
- Pneumatic circuit design using 3-port selector/divider architecture
- AC/DC solenoid coil circuits with full-wave rectification (where applicable)
