Overview
The SMC RSDQA32-15D pneumatic cylinder is a compact, double acting actuator engineered for precise motion control in industrial automation applications. With a 32mm bore and 15mm stroke, this cylinder provides reliable performance in systems requiring controlled linear actuation within confined spaces. The unit is supplied new in box and ready for immediate integration into your pneumatic system.
Key Features
- Double acting design for push and pull motion control
- Compact footprint suitable for space-constrained installations
- Built-in magnet for compatible proximity switch mounting
- Aluminum alloy construction for lightweight durability
- Standard porting for quick integration with pneumatic networks
Technical Specifications
- Bore Diameter: 32mm
- Stroke Length: 15mm
- Operating Pressure: 0–1.0 MPa (0–10 bar, 0–145 psi)
- Action Type: Double Acting
- Port Size: M5 (standard)
- Rod Design: Single rod
- Mounting Style: Foot / Flange options available
- Operating Temperature Range: 0–70°C
- Weight (approx.): 0.2 kg
Typical Applications
The RSDQA32-15D is ideal for use in:
- Precision pick-and-place automation
- Clamping and holding mechanisms
- Light-duty material handling systems
- Assembly line positioning and control
- Machine tool automation and indexing
Compatibility & Replacements
Compatible With
- SMC pneumatic valve manifolds (standard porting)
- SMC solenoid valve blocks and directional control valves
- Standard 1/4″ pneumatic tubing and fittings
- SMC proximity switches and sensor systems (with built-in magnet)
- Industrial pneumatic control systems operating 0–10 bar
Replaces / Drop-In Replacement For
- Similar compact cylinders in SMC’s RSDQA and CDQ series with 32mm bore and 15mm stroke
- Verify part number compatibility with your system integrator before ordering
Works With
- SMC pneumatic control software and system design tools
- Standard pneumatic automation networks
- M5 threaded ported solenoid valve systems
- Manual and electronic pneumatic valve control
