Overview
The SMC CQ2B12-F4527-15 is a compact double-acting pneumatic cylinder engineered for versatile industrial automation. Part of the industry-standard CQ2 series, this 12mm bore cylinder delivers reliable, responsive performance in demanding environments. The CQ2 series is the world’s best-selling compact cylinder line, trusted by manufacturers worldwide for motion control in robotics, assembly, material handling, and process automation.
Key Features
- 12mm bore size for space-constrained applications
- Double-acting design for extended push and pull strokes
- Compact footprint for equipment downsizing
- Single rod piston configuration
- Threaded piston rod for quick attachment of actuators and sensors
- Proven durability and global parts availability
Technical Specifications
Specifications for the CQ2B12 series:
- Bore Diameter: 12 mm
- Cylinder Type: Double Acting, Single Rod
- Series: CQ2 Compact Cylinder
- Piston Rod: Male or female threaded (configuration-dependent)
- Standard Strokes: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100, 125, 140, 160, 180, 200 mm
- Operating Pressure Range: 0–1.0 MPa (typical for CQ2 series)
- Mounting: Multiple surface options for ø12 bore
- Certifications: Meets ISO 286 and other international standards
Typical Applications
- Robotic pick-and-place and handling systems
- Automated assembly and manufacturing lines
- Material positioning and clamping
- Packaging and labeling equipment
- Medical device and laboratory automation
- Food processing and pharmaceutical operations
Compatibility & Replacements
Compatible With
- Standard ISO 15218 pneumatic manifold and valve connections
- SMC pneumatic control systems and solenoid valves
- Industry-standard air fittings and tubing (metric and inch sizes)
- Pneumatic circuit design software and CAD libraries
Replaces / Drop-In Replacement For
- Other CQ2B12 variants with matching stroke and mounting specifications
- Verify specific stroke and rod configuration before ordering to ensure direct compatibility
Works With
- SMC solenoid valves and pneumatic control modules
- Pressure regulators and air preparation units
- Proximity sensors and position switches
- PLC and motion control systems via pneumatic logic or sensor feedback
- Industry-standard compressed air infrastructure
