Overview
The SMC CDM2D25-50Z is a compact double-acting pneumatic cylinder engineered for precision automation applications. This cylinder delivers reliable linear motion in confined spaces, making it ideal for machinery where compact footprint is critical. The CDM2D25-50Z combines space-efficient design with durable construction, suitable for diverse industrial control systems.
Key Features
- Compact body design minimizes installation space
- Double-acting configuration for push and pull force
- Built-in magnet for proximity and position sensing
- Auto-switch mounting grooves for easy sensor integration
- Reliable performance across standard industrial pressure ranges
- Aluminum alloy body for lightweight, corrosion-resistant operation
Technical Specifications
- Bore Diameter: 25mm
- Stroke Length: 50mm
- Cylinder Type: Double-acting, single rod
- Operating Pressure Range: 0.1–1.0 MPa (typical)
- Port Type: M5 × 0.8 (standard)
- Rod Diameter: 8mm
- Body Material: Aluminum alloy
- Mounting: Foot, flange, and clevis options available
- Operating Temperature: 0–60°C (standard air)
- Weight: Approximately 0.3 kg (exact weight subject to mounting options)
Typical Applications
The CDM2D25-50Z is widely used in:
- Packaging and labeling machinery
- Transfer and positioning systems
- Assembly line automation
- Material handling and clamping
- Machine tool fixtures and work-holding devices
- Food and beverage processing equipment
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems (ISO 4401 cavity)
- SMC manifold blocks and valve stations
- Pneumatic directional control valves (4/2, 5/2, 5/3 solenoid and manual)
- Auto-switch proximity sensors (SMC D-M9, D-A9 series)
- Proportional flow control valves
- Logic-based pneumatic controllers and PLCs with pneumatic interfaces
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The CDM2D series may interchange with older CM2 single-rod compact cylinders of matching bore and stroke; however, always confirm mounting patterns and port thread specifications with original equipment specifications.
Works With
- SMC valve and manifold systems (standard ISO and CETOP cavity standards)
- Proportional directional control valves
- Solenoid directional control valves
- Manual pilot-operated directional control valves
- Flow control valves and speed regulators
- Pressure relief and filter/regulator assemblies
- Compressed air supply systems (filtered, regulated, lubricated)
