Overview
The Sick 6058511 DOL-0804-G05MRN cordset is a professional-grade sensor-actuator cable designed for industrial automation and control systems. This single-ended connector cable delivers reliable connectivity in demanding applications, featuring a durable polypropylene jacket and stainless steel hardware that resists corrosion in harsh environments.
Key Features
- M8 Female Connector: 4-pin straight configuration ensures secure mating with M8 socket connectors
- Flying Leads: Opposite end terminates in individual flying leads for direct integration into control systems
- Stainless Steel Hardware: V4A/1.4404/316L locking nut provides corrosion resistance and durability
- Gray PP Jacket: Polypropylene outer sheath rated for flexible applications with high bending cycle tolerance
- Unshielded 4-Wire Design: Suitable for digital signal transmission and low-voltage sensor connections
Technical Specifications
The cable construction meets the DOL series standard with 5-meter length, 4-wire configuration, and optimized conductor sizing for reliable signal integrity. The unshielded design reduces bulk while maintaining performance in typical industrial electromagnetic environments.
Typical Applications
- Proximity sensors and position switches
- Inductive and capacitive sensor integration
- Industrial control and safety circuits
- Machine automation and material handling systems
- Factory automation signal transmission
Compatibility & Replacements
Compatible With
- Sick M8 4-pin socket connectors (female receptacles)
- Industrial PLC sensor input modules
- M8 sensor-actuator automation ecosystems
- Standard 24V industrial control circuits
Replaces / Drop-In Replacement For
- Equivalent Sick DOL-0804 series cordsets with same 5m length and M8 female 4-pin straight connector configuration
- Original equipment manufacturer (OEM) sensor cables in standard industrial automation systems
Works With
- Sick plug connector and cable ecosystem
- M8 standardized sensor connector networks
- Industrial Ethernet and discrete I/O automation platforms
