Overview
The Motorola 6-6341 is a vintage New Old Stock (NOS) fixed resistor designed for general-purpose electronic applications. This through-hole component provides a nominal resistance of 22K Ohm with a 1W power rating and ±10% tolerance, making it suitable for classic consumer electronics, industrial control circuits, and repair work where original Motorola components are preferred or required.
Key Features
- Resistance Value: 22K Ohm (22,000 Ω)
- Power Rating: 1 Watt continuous dissipation
- Tolerance: ±10% at 25°C
- Condition: New Old Stock (NOS) – untested, original packaging
- Construction: Carbon film or wire-wound fixed resistor (typical for 1W Motorola vintage stock)
- Ideal for vintage radio, TV, audio equipment, and industrial control repairs
Technical Specifications
- Nominal Resistance: 22 kΩ
- Power Dissipation (Rated): 1 W
- Tolerance Grade: ±10%
- Temperature Coefficient: Typical 100–500 ppm/°C (standard for vintage carbon/film resistors)
- Operating Temperature Range: −55 to +125°C (typical for industrial-grade components)
- Mounting Style: Through-hole (axial leads)
- Series/Source: Motorola Resistor File Pack
Typical Applications
- Vintage consumer electronics (radios, televisions, audio amplifiers)
- Industrial control circuits and machinery
- Equipment restoration and repair projects
- Circuit prototyping and engineering development
- Educational demonstrations and hobby electronics
- High-impedance biasing networks and load resistances
Compatibility & Replacements
Compatible With
- Vintage electronic test equipment and vintage consumer audio/radio gear
- Industrial control systems and relay circuits from the 1960s–1980s era
- Any 1W through-hole resistor footprint design with 22 kΩ resistance requirement
- Standard 0.25 inch lead spacing typical of Motorola resistor file packs
Replaces / Drop-In Replacement For
- Original equipment manufacturer (OEM) Motorola 22K Ohm 1W resistors in vintage radios, televisions, and audio systems
- Generic 22K Ohm 1W carbon film or wire-wound fixed resistors (1/4 inch lead spacing)
- Verify your equipment schematic before ordering to confirm exact resistance value and power rating
Works With
- Standard breadboards and through-hole circuit boards
- Vintage tube radio and amplifier restoration projects
- Analog circuit design and prototyping
- Industrial relay and control logic circuits
- Any design requiring a high-impedance load or voltage divider network
