Overview
The Allen-Bradley RCR07G561JS is a fixed carbon composition resistor designed for industrial and electronic applications requiring dependable performance. With a nominal resistance of 560Ω and a 5% tolerance rating, this resistor offers consistent electrical characteristics across operating conditions. Supplied in a complete box of 1000 units, it is ideal for high-volume manufacturing, maintenance stocking, or replacement programs. These resistors meet military standards and have been used reliably in demanding applications for decades.
Key Features
- Resistance Value: 560Ω nominal with ±5% tolerance
- Power Rating: 0.25W (250mW) continuous duty
- Construction: Hot-molded carbon composition with oxygen-free copper leads
- Bulk Quantity: 1000-unit box for production efficiency and inventory management
- Military Qualification: U.S. military-qualified design for proven reliability in critical applications
- Temperature Range: Operating range up to 70°C
Technical Specifications
- Resistance: 560Ω
- Tolerance: ±5%
- Power Rating: 0.25W
- Temperature Coefficient: ±1000 ppm/°C (typical)
- Lead Material: Oxygen-free copper
- Maximum Operating Temperature: 70°C
- Packaging: 1000 units per box
- Compliance: MIL-R-39008 carbon composition resistor standard
Typical Applications
- Industrial control panel assemblies
- Legacy equipment retrofit and maintenance
- Prototype development and breadboarding
- Load resistors and bias networks
- Frequency-dependent biasing circuits
- Test fixture and measurement equipment
Compatibility & Replacements
The RCR07G561JS is a direct replacement for earlier Allen-Bradley carbon composition resistors of identical value and power rating. These components are broadly compatible with any circuit designed for a 560Ω, 0.25W, 5% tolerance resistor. While modern thin-film or metal-film resistors may offer tighter tolerances and lower temperature coefficients, the RCR07G series maintains compatibility with legacy designs and environments where proven carbon composition characteristics are specified or required.
