Overview
The Hokuyo DC-NXB is a reliable automatic counter timer designed for industrial counting and timing applications. This discontinued unit features a 6-digit LCD display for clear count readout and operates across standard universal voltage (100-240 VAC, 50/60 Hz). The DC-NXB is compact and well-suited for process control, batch counting, and production monitoring in manufacturing environments where legacy equipment replacement or system upgrades are required.
Key Features
- 6-digit LCD display for easy count visibility
- 30 CPS (counts per second) counting speed for reliable pulse capture
- Universal AC power input (100-240 VAC, 50/60 Hz)
- Compact 60×60 mm panel-mount design
- Discontinued by manufacturer – ideal for legacy system replacement
- Fully functional, tested unit ready for deployment
Technical Specifications
- Model: Hokuyo DC-NXB
- Product Type: Automatic Counter Timer
- Input Power: 100-240 VAC, 50/60 Hz
- Display: 6-digit LCD
- Count Speed: 30 CPS (counts per second)
- Panel Mounting: 60×60 mm front panel cutout
- Manufacturer Status: Discontinued
- Application: Industrial counting, timing, production control
Typical Applications
The Hokuyo DC-NXB is used in:
- Batch counting and production line monitoring
- Process timing control in manufacturing
- Pulse counting from sensors and switches
- Legacy system upgrades and replacements
- Industrial automation control panels
- Quality assurance and production tracking
Compatibility & Replacements
Compatible With
- Standard industrial 100-240 VAC power supplies
- Contact and transistor-based pulse inputs
- Panel-mount applications with 60×60 mm cutout
- Industrial automation and process control systems
Replaces / Drop-In Replacement For
The Hokuyo DC-NXB is a direct replacement for discontinued Hokuyo counter/timer units in legacy 60×60 mm panel installations. Verify compatibility with your system integrator before ordering to ensure terminal configuration and mounting requirements match your application.
Works With
- Standard industrial control panel designs
- AC power distribution systems (100-240 VAC rated)
- Sensor inputs and switch closures
- Relay output wiring for count/timing events
