Overview
The Allen-Bradley 700-P800A1 is a NEMA A600-rated industrial control relay from Rockwell Automation’s trusted Bulletin 700 series. This heavy-duty AC relay delivers reliable performance in machine tool controls, motor starters, and general industrial switchboard applications. With 8 normally open contacts and a 10A AC contact rating, the 700-P800A1 operates on a 120V coil (110V 50Hz / 115-120V 60Hz) and supports up to 600V AC systems. The open-type design with DIN rail mounting makes it ideal for retrofit and new installation projects in demanding electrical environments.
Key Features
- 8 normally open (NO) contacts—configurable via convertible contact cartridges
- 10A AC contact rating at 600V AC maximum voltage
- 120V AC coil (110V 50Hz / 115-120V 60Hz) for standard North American power systems
- Open-type DIN rail mount for easy panel integration and maintenance
- Heavy-duty NEMA A600 construction rated for machine tool and industrial controls
- Finger-safe protection standard on all models
Technical Specifications
Contact configuration, voltage ratings, and thermal performance:
- Contact Configuration: 8 Normally Open (NO)
- Contact Rating: 10A AC at 600V AC
- Coil Voltage: 110V 50Hz / 115-120V 60Hz
- Maximum System Voltage: 600V AC / DC
- Mounting Type: Open Type DIN Rail Mount
- Series: NEMA A600 / Bulletin 700 (Type P)
- Certifications: CE, CSA, CUL, KC, Marine, UL
Typical Applications
The 700-P800A1 is widely used in:
- Machine tool motor control and interlocking circuits
- Switchboard and electrical equipment control logic
- Industrial automation and relay-based control systems
- HVAC and process control applications requiring modular relay configurations
- General-purpose AC switching and sequencing circuits
Compatibility & Replacements
The Allen-Bradley 700-P800A1 is part of the modular Bulletin 700 relay family, which allows for coil and contact cartridge substitution. Engineers can swap 8, 10, or 12-pole contact configurations without changing the base relay, simplifying inventory and system design. The 120V coil designation makes it directly compatible with standard North American industrial control circuits. When sourcing alternatives or cross-platform solutions, consult Rockwell Automation technical documentation or contact support to verify contact arrangement compatibility with your application.
