Overview
The Allen-Bradley 700-P800A1 is a NEMA-rated heavy-duty industrial relay engineered for demanding machine tool and motor control applications. Part of the Bulletin 700-P modular relay family, this relay combines convertible contact architecture with finger-safe protection to deliver reliable switching in control circuits. With its modular design and proven performance in industrial environments, the 700-P800A1 serves as a critical component in switchboards, electrical hold control, and complex automation systems.
Key Features
- 8 normally open (N.O.) contacts for flexible load switching configurations
- 10 Amp AC contact rating suitable for standard industrial loads
- 120V AC coil (110V @ 50Hz, 115–120V @ 60Hz) for North American control circuits
- 600V AC/DC maximum voltage withstand capability
- NEMA and IEC rated for industrial reliability and global compliance
- Open-type DIN rail mount design for panel integration
- Convertible contact cartridges enabling custom relay configurations
- Finger-safe protection standard for operator safety
Technical Specifications
The relay features the following electrical and mechanical characteristics:
- Contact Configuration: 8 N.O. (Normally Open)
- Contact Rating: 10 Amp AC
- Maximum Voltage: 600V AC/DC
- Coil Voltage: 110V @ 50Hz / 115–120V @ 60Hz
- Mounting: Open Type DIN Rail Mount
- Series: Bulletin 700-P NEMA Heavy-Duty
- Certifications: CE, CSA, CUL, KC, UL, Marine approved
- Protection Level: Finger-safe contacts standard
- Design Type: Modular, convertible contact cartridge system
Typical Applications
The 700-P800A1 excels in:
- Machine tool motor control and switchboard applications
- Electrical hold control circuits requiring multiple switching paths
- Industrial automation systems with NEMA-rated enclosures
- Distributed control systems where modular relay architecture simplifies maintenance
- Systems requiring convertible contact configurations without rewiring
Compatibility & Replacements
The Allen-Bradley 700-P800A1 integrates seamlessly with standard industrial control components and Rockwell Automation products. Engineers selecting this relay should verify coil voltage compatibility with existing control circuit specifications and confirm contact rating adequacy for intended loads. Related 700-P models (4NO, 4NC variants) and alternative Bulletin 700-T timing relays are available for different application requirements. For replacement decisions, consult the Rockwell Automation compatibility matrix or contact technical support to ensure proper interchangeability within your existing control architecture.
