Overview
The Hoffman A-1008SC is a Type-12 screw cover enclosure designed for general-purpose indoor electrical installations. This junction box combines a durable 14-gauge steel construction with a gray polyester powder coat finish, delivering reliable component protection in control cabinets, distribution systems, and junction applications. The A-1008SC is available in used condition, tested and ready for deployment as a cost-effective replacement or secondary enclosure solution.
Key Features
- Type-12 NEMA rating protects against dust, moisture, and corrosion in general indoor environments
- 14-gauge mild steel body with polyester powder coat finish for durable protection
- Screw-down cover design allows quick access while maintaining a positive seal when secured
- Wall-mount bracket provisions for easy installation and alignment
- Gray ANSI 61 color standard finish for industrial aesthetic consistency
- Compact footprint suitable for retrofit and space-constrained installations
Technical Specifications
- Manufacturer: Hoffman (nVent)
- Model Number: A-1008SC
- Type Rating: NEMA Type 12
- Material: 14-gauge mild steel
- Finish: Polyester powder coat gray (ANSI 61)
- Height: 10 inches
- Width: 8 inches
- Depth: 4 inches
- Cover Style: Screw-down cover with corner fasteners
- Mounting: Indoor wall mount with bracket provisions
- Condition: Used
Typical Applications
- Electrical panel sub-enclosures and secondary junction boxes
- Terminal block and control device mounting
- Cable entry and wire management in factory and plant environments
- Low-voltage component protection (rated for up to 1000V AC / 1500V DC assemblies)
- Equipment retrofit and panel modification projects
- Industrial and commercial HVAC, machinery, and motor control installations
Compatibility & Replacements
Compatible With
- Standard electrical panel mounting systems and wall-mounted enclosure racks
- DIN rail components, terminal blocks, and control modules
- Industiral control circuits rated up to 1000V AC or 1500V DC
- Optional Hoffman backplates and mounting kits (A10P8 steel, A10P8G conductive, or A10P8AL aluminum)
Replaces / Drop-In Replacement For
- Other 10″ × 8″ × 4″ Type-12 screw cover junction boxes from third-party manufacturers
- Verify specific compatibility with your system integrator or controls engineer before ordering
Works With
- Universal electrical panel assembly and wiring protocols
- All NEMA and IEC standard electrical components rated for Type-12 enclosures
- Optional accessory panels and thermal management solutions
