Overview
The Hoffman A30P24 is a replacement and OEM enclosure panel manufactured by nVent Hoffman for standard Type 3R, 4, 4X, 12, and 13 industrial control enclosures. This panel is ideal for applications requiring a solid, painted steel replacement for damaged, worn, or custom-configured enclosures in manufacturing, power distribution, and controls environments.
Key Features
- 12-gauge steel construction — durable, corrosion-resistant painted finish suitable for indoor and outdoor NEMA-rated environments
- White polyester powder coating — professional appearance with long-lasting corrosion protection
- Four pre-drilled mounting holes — ready for immediate installation without additional machining
- Universal compatibility — fits all standard 30×24 enclosure frames rated NEMA 3R, 4, 4X, 12, and 13
- Mounting hardware included — panel fasteners supplied with each unit for quick installation
- UL/NEMA certified — meets industrial safety and environmental ratings for OEM replacement
Technical Specifications
- Part Number: A30P24 (Model 23200)
- Dimensions: 21″ W × 27″ H (533 mm × 686 mm)
- Enclosure Fit: 30″ × 24″ frame
- Material: Steel
- Gauge: 12 gauge
- Finish: White polyester powder coat
- Mounting Holes: 4 pre-drilled
- NEMA Type Rating: 3R, 4, 4X, 12, 13
- Hardware: Mounting hardware included
- UPC: 783510232009
- Manufacturer: nVent Hoffman
Typical Applications
- Replacement panels for industrial control enclosures in manufacturing plants and process facilities
- OEM spare parts for standard 30×24 electrical distribution enclosures
- Custom enclosure configurations and panel modifications in control systems
- NEMA 12 (dust-tight, drip-proof) wall-mounted control panel environments
- Maintenance and upgrade projects for existing industrial automation equipment
- Arc flash safety and controls applications in corrosive or demanding industrial settings
Compatibility & Replacements
Compatible With
- nVent Hoffman Type 3R, 4, 4X, 12, and 13 enclosures — 30×24 frame size
- Standard NEMA-rated electrical enclosure systems
- Industrial control cabinet manufacturers using 30×24 panel slots
- Most OEM enclosure assemblies requiring 12-gauge steel replacement panels
- Wall-mount and free-standing enclosure configurations
Replaces / Drop-In Replacement For
- Original Hoffman A30P24 panels (direct replacement)
- Damaged or worn 30×24 NEMA-rated enclosure panels
- Legacy panel configurations requiring 21″ × 27″ dimensions
Works With
- Hoffman enclosure frame sizes 30″ W × 24″ D
- Standard industrial mounting hardware and fastening systems
- Existing NEMA 3R, 4, 4X, 12, 13 rated enclosure assemblies
- Control panel manufacturers and systems integrators
