Overview
The Hayward 1-1/2″ PVC ball valve with Full-Flo design delivers dependable flow control for a wide range of industrial and commercial fluid handling systems. Built from high-quality PVC material, this full-port ball valve minimizes pressure drop and turbulence, making it suitable for applications requiring efficient flow with low maintenance. The full-port design ensures the internal passage is as large as the pipe diameter, eliminating flow restrictions.
Key Features
- Full-port design for unrestricted flow with minimal pressure drop
- Full-port design and fully sphere shape ball construction
- 1-1/2″ nominal size with standard NPT or socket connections
- PTFE seats and EPDM or FPM O-rings for reliable sealing
- Handle retained without metal fasteners and made from GFPP with UV Inhibitor
- Double O-ring stem seal design prevents leakage and extends service life
Technical Specifications
1/4″ – 2″ ball valves are pressure-rated for 250 PSI at 70°F non-shock. The valve features blowout proof stem design for enhanced safety. Chemical resistance inherent to PVC construction makes this valve compatible with most aqueous fluids, acids, bases, and non-hydrocarbon solutions.
Typical Applications
- Water treatment and recirculation systems
- Chemical processing and fluid distribution
- Agricultural and irrigation systems
- HVAC and cooling loops
- Industrial flow control and isolation
Compatibility & Replacements
Compatible With
- Standard PVC piping systems with NPT or socket connections
- Systems rated for 250 PSI maximum operating pressure
- Fluids compatible with PVC and PTFE materials
- Manual lever or motorized actuator control systems
Replaces / Drop-In Replacement For
While this unit is a standard Hayward 1-1/2″ full-port ball valve design, verify your specific model number and connection type (NPT threaded, socket, or union) with your system integrator before ordering to ensure proper fit and compatibility with your existing piping.
Works With
- ISO 5211 actuator mounting patterns (if applicable to your model)
- Manual lever handles for quarter-turn operation
- Standard industrial actuators rated for 250 PSI service
- PVC and CPVC piping systems
