Overview
The DynaQuip 189024-1 is a 115VAC electric actuated ball valve featuring a lock rotor motor with 0.55A nominal current draw and 100 in-lb torque output. This unit is designed for applications requiring automated on/off flow control in hydraulic, pneumatic, pump, and plumbing systems. The assembly combines the valve body with an integrated electric actuator, providing a compact, ready-to-mount solution for industrial automation and process control.
Key Features
- Lock rotor electric motor for high starting torque and holding force
- 100 in-lb (approximately 11.3 Nm) torque output suitable for 1/2″ to 1″ ball valves
- 115VAC single-phase input with 0.55A current rating
- Integrated AE104 actuator design for direct mounting to standard ball valve bonnets
- Manual override capability for fail-safe operation
- Compact, all-in-one actuator and valve assembly minimizes installation footprint
Technical Specifications
- Input Voltage: 115VAC, 50/60 Hz, single phase
- Motor Current: 0.55A nominal
- Torque Output: 100 in-lb (11.3 Nm)
- Actuator Type: Lock rotor electric motor with manual override
- Valve Configuration: 2-way, 2-position (open/close)
- Body Material: Brass or ductile iron (standard DynaQuip construction)
- Connection Type: NPT or FNPT (threaded)
- Operating Pressure: Rated for general industrial applications up to 150 psi (verify for specific service)
- Cycle Time: Approximately 4–6 seconds (typical for 100 in-lb motors)
- Manufacturer: DynaQuip Controls, St. Clair, Missouri, USA
Typical Applications
- Hydraulic system shutoff and flow control
- Pneumatic circuit isolation and actuation
- Pump discharge pressure relief and bypass control
- Plumbing and water treatment system automation
- Industrial process control and equipment startup/shutdown sequences
- Agricultural and mobile equipment fluid system management
Compatibility & Replacements
Compatible With
- Standard 115VAC single-phase power supplies (50/60 Hz)
- Manual solenoid control switches and timers
- Industrial control panels and PLCs via relay outputs
- Limit switches for position feedback (if accessory mounted)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The DynaQuip 189024-1 is a specific model designed as part of DynaQuip’s electric actuator line; equivalent torque and voltage models from DynaQuip may include other AE-series actuators, but direct interchangeability requires matching valve body, port configuration, and actuator mounting.
Works With
- DynaQuip AE-series electric actuators and control accessories
- Standard industrial ball valve body assemblies (NPT/FNPT connections)
- Common industrial control protocols (hardwired 115VAC relay logic; not Ethernet or fieldbuses)
- Manual valve overrides and mechanical lockout devices for maintenance safety
