Overview
The Festo DSBC-40-150-PPSA-N3 is an ISO 15552 standards-based double-acting pneumatic cylinder engineered for demanding industrial automation applications. With a 40mm bore diameter and 150mm stroke length, this compact yet powerful actuator delivers consistent force and speed control in manufacturing, packaging, assembly, and material handling systems. The DSBC series combines proven design with field-tested reliability, making it an ideal choice for OEM equipment builders and system integrators requiring drop-in compatibility with existing pneumatic networks.
Key Features
- Double-acting design with adjustable pneumatic cushioning at both ends
- High-alloy steel piston rod for extended service life and reduced maintenance
- Compact profile-cylinder construction per ISO 15552 standard
- 12 bar (1.2 MPa) maximum operating pressure rating
- Suitable for position sensing with optional proximity sensor compatibility
- SAE and ISO ported connections for flexible system integration
Technical Specifications
The DSBC-40-150-PPSA-N3 delivers repeatable performance with minimal deviation. Its steel construction and sealed design protect against dust and moisture ingress in shop-floor environments. The cushioning mechanism absorbs shock loads, extending component life and reducing noise in high-cycle applications.
Typical Applications
- Packaging machinery and labeling systems
- Assembly line tooling and part clamping
- Material handling and transfer automation
- Press and die-cutting equipment
- Industrial robotic end-of-arm tooling (EOAT)
- Test and inspection fixtures
Compatibility & Replacements
Compatible With
- ISO 15552 standard valve manifolds and porting blocks
- SAE ported directional control valves
- Pneumatic tubing and quick-disconnect couplers (8mm, 10mm, 12mm)
- Festo valve systems and proportional controls
- Position sensing systems (inductive, capacitive, reed sensors)
- Industry-standard pneumatic networks (0.5–12 bar operating range)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Cross-reference with legacy Festo DSBC cylinders of the same bore and stroke specifications.
Works With
- Festo FluidSIM simulation and design software
- Pneumatic system design tools and CAD libraries
- Standard air preparation units and distribution systems
- ISO 4401-05 (CETOP-05) solenoid valve interfaces
