Overview
The Allen-Bradley 2711P-RP8D is a high-performance logic module that powers and controls PanelView Plus 6 operator terminals in the 700 to 1500 size range. This module provides the processing power, memory, and communication capabilities essential for industrial HMI applications. Operating under Windows CE 6.0, it delivers robust performance in demanding manufacturing and process automation environments.
Key Features
- Substantial Memory: 512 MB of RAM and 512 MB of flash storage, with approximately 79 MB available for user applications
- Dual Communication Ports: Supports both Ethernet and RS-232 communication for versatile connectivity
- Network Expansion: Features a network interface that accommodates additional communication modules, enhancing its versatility
- Marine Certification: Designed for maritime applications, this logic module is marine certified, ensuring reliability in such settings
- Compact Design: Lightweight module (1.26 lbs) suitable for space-constrained installations
- Wide Operating Range: Functions well in temperatures from 0 to 55 degrees Celsius and can operate effectively in areas with non-condensing relative humidity levels between 5 and 95%
Technical Specifications
- Memory: 512 MB Flash / 512 MB RAM (79 MB user-available)
- Operating System: Windows CE 6.0
- Power Input: 24 VDC
- Power Consumption: 70 Watts
- Communication Ports: Ethernet, RS-232, Network Interface Module slot
- Compatible Series: PanelView Plus 6 (700-1500 terminal range)
- Operating Temperature: 0 to 55°C
- Humidity: 5% to 95% non-condensing RH
- Weight: 1.26 lbs
- Certifications: C-TICK, CCC, KC
Typical Applications
- HMI terminal replacement and repair for PanelView Plus 6 systems
- Industrial process monitoring and control operator interfaces
- Manufacturing equipment supervision and diagnostics
- Marine and offshore automation systems (marine-certified)
- Food and beverage processing control
- Automotive manufacturing operator stations
Compatibility & Replacements
Compatible With
- Panelview Plus 6 terminals that fall within the range of 700 to 1500 models
- Rockwell Automation control systems supporting Windows CE 6.0
- Networks using Ethernet or RS-232 protocols
- FactoryTalk View Machine Edition
- Additional communication modules via network interface slot
Replaces / Drop-In Replacement For
The 2711P-RP8D is the standard logic module for all PanelView Plus 6 terminals in the 700-1500 range. It directly replaces any failed or damaged logic module in these units. Verify compatibility with your system integrator before ordering to ensure proper terminal size and configuration match.
Works With
- FactoryTalk View Machine Edition HMI software
- Windows CE 6.0 operating environment
- Rockwell Automation Integrated Architecture solutions
- Ethernet-based industrial networks
- RS-232 serial communication devices
- CompactFlash expansion cards (via module slot)
