Overview
The Allen-Bradley 800T-XA is a high-quality 30mm shallow contact block designed to deliver reliable switching control in demanding industrial environments. This contact block serves as a core accessory for the 800T and 800H series of 30mm pushbuttons, providing a 1 Normally Open (NO) and 1 Normally Closed (NC) contact configuration. With a 600VAC voltage rating and 10A contact current capacity, the 800T-XA offers proven durability and performance for control circuits in manufacturing, process automation, and facility management applications.
Key Features
- 1 Normally Open / 1 Normally Closed contact configuration for dual-state control logic
- 30mm form factor compatible with 800T and 800H series pushbuttons
- Base mounting with screw terminal attachment for secure installation
- Non-metallic construction rated for 600VAC, 10A at 230VAC
- UL, CSA, CE, and CCC certifications for global regulatory compliance
- Shallow contact block design for compact panel installations
Technical Specifications
| Part Number | 800T-XA |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| Product Type | Contact Block |
| Contact Configuration | 1 Normally Open (NO) / 1 Normally Closed (NC) |
| Voltage Rating | 600VAC |
| Contact Current Rating | 10A at 230VAC |
| Mounting Type | Base Mount |
| Terminal Type | Screw Terminals |
| Size | 30mm |
| Material | Non-Metallic |
| Dimensions | 1.42″ L × 1.78″ H |
| Weight | 0.09 lbs |
| Certifications | UL, CSA, CE, CCC, MARINE-ABS |
| Condition | New in Box |
Typical Applications
- General-purpose control circuits requiring dual contact logic (start/stop, forward/reverse)
- Industrial pushbutton stations for motors, conveyors, and pump control
- Emergency stop (E-stop) and safety circuit integration with compatible pushbuttons
- Manufacturing and process automation plant floor control
- HVAC systems, compressor control, and facility automation
- Replacement contact blocks for existing 800T and 800H installations
Compatibility & Replacements
Compatible With
- Allen-Bradley 800T series 30mm pushbuttons
- Allen-Bradley 800H series 30mm pushbuttons
- Standard industrial control panels rated 600VAC
- Base-mount control circuit architectures
- Rockwell Automation automation systems requiring discrete contact switching
Replaces / Drop-In Replacement For
- Original equipment 800T-XA contact blocks in 800T and 800H pushbutton stations
- Legacy 30mm contact blocks requiring 1NO/1NC configuration
- Worn or failed contact blocks in existing industrial control systems
Works With
- Allen-Bradley 800T and 800H pushbutton series
- Discrete 600VAC control circuits
- Industrial relay logic and hardwired automation systems
- Standard control panel wiring and terminal block layouts
- Non-networked control architectures (standalone pushbutton applications)
