Overview
The Allen-Bradley 800H-PRB16R is a heavy-duty 30mm momentary pushbutton operator from Rockwell Automation’s proven 800H series. This unit features red color identification with incandescent illumination powered by a 120V AC transformer, making it ideal for visual indication and status confirmation in industrial control panels and automation stations. The pushbutton delivers momentary contact operation with standard electromechanical reliability across NEMA Type 4, Type 4X, and Type 13 environments.
Key Features
- 30mm pushbutton operator with red cap and extended head design
- Momentary contact operation with standard 1 NO / 1 NC configuration
- Incandescent lamp illumination powered by 120V AC 50/60 Hz transformer
- Type 4, 4X, and 13 rated for severe industrial environments
- Extended head without guard for panel-mount applications
- Plastic construction with no guards on terminals
- Compatible with standard 800H series contact blocks and accessories
Technical Specifications
- Operator Size: 30mm diameter
- Operating Mode: Momentary
- Button Color: Red
- Illumination Type: Incandescent
- Illumination Power: 120V AC 50/60 Hz transformer-supplied
- Standard Contact Configuration: 1 NO / 1 NC contacts
- Head Style: Extended head without guard
- Material: Plastic (thermoplastic polyester resin construction)
- Certification: UL Listed, CE marked, CSA Listed Hazardous, China CCC
- Operating Temperature: Below freezing based on absence of moisture and liquids
- Lifecycle Status: Active (as of August 2025)
- Rockwell Automation Publication: 800-TD009L-EN-P
Typical Applications
The 800H-PRB16R is commonly deployed in:
- Industrial control panels and electrical enclosures
- Machine automation start/stop stations
- Process control and monitoring systems
- Emergency stop and safety-rated circuits (when configured with appropriate contact blocks)
- Equipment requiring visual feedback and operator indication
- Assembly line and manufacturing floor control stations
- Food processing, automotive, and heavy industry installations
Compatibility & Replacements
Compatible With
- Rockwell Automation 800H series contact blocks and carriers
- 800H base stations and frame assemblies
- Allen-Bradley standard transformer power modules (120V AC)
- Type 4, 4X, and 13 rated enclosures
- NEMA-compliant industrial control systems
Replaces / Drop-In Replacement For
- Earlier generations of 800H momentary red pushbuttons
- Verify compatibility with your system integrator before ordering to confirm switch configuration matches your application requirements
Works With
- Rockwell Automation 800H / 800T series platforms
- Standard NEMA industrial automation enclosure wiring
- Incandescent lamp modules rated 120V AC 50/60 Hz
- Modular contact block systems for custom circuit configurations
