Overview
The Allen-Bradley 889D-F4NEDM-2 is a Bulletin 889D DC Micro cable cordset designed for quick-disconnect sensor connectivity in industrial control systems. This 2-meter cordset connects 4-pin M12 DC Micro female straight (sensor end) to 4-pin M12 DC Micro male straight (input/output end) with 18 AWG conductors. The unshielded red PVC jacket resists oil and chemicals, making it suitable for harsh factory and manufacturing environments where reliable component interconnection is essential.
Key Features
- 4-pin M12 DC Micro straight connectors (female-to-male configuration)
- 2-meter cable length for flexible sensor positioning
- 18 AWG conductor size for standard industrial signal applications
- Red PVC jacket with chemical and oil resistance
- Unshielded construction for cost-effective dc micro applications
- Epoxy-coated zinc connector hardware for durability
Technical Specifications
- Cable Length: 2 meters (6.56 feet)
- Connector Type (End 1): 4-Pin M12 DC Micro Straight Female (Sensor)
- Connector Type (End 2): 4-Pin M12 DC Micro Straight Male (I/O)
- Wire Gauge: 18 AWG
- Cable Jacket: Red PVC, Unshielded
- Number of Pins: 4
- Connector Material: Epoxy-coated zinc
- Cable Type: Unshielded
- Color: Red
- UPC: 889508628332
Typical Applications
The 889D-F4NEDM-2 cordset is used in:
- Machine tool sensor connections
- Industrial process automation networks
- Proximity and limit switch wiring
- DC micro quick-disconnect sensor systems
- Manufacturing control cabinet installations
- Equipment retrofits and field replacements
Compatibility & Replacements
Compatible With
- Allen-Bradley Bulletin 889 DC Micro sensors and actuators
- Any system or device with 4-pin M12 DC Micro female and male connectors
- Industrial control systems requiring IEC 61076-2-109 M12 connectivity
- Machine automation platforms using standard DC micro quick-disconnect
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 889D-F4NEDM-2 is designed as a direct replacement for existing Bulletin 889D cordsets of the same connector configuration and cable length.
Works With
- Allen-Bradley Bulletin 889 sensor product family
- M12 DC Micro quick-disconnect systems
- IEC 61076-2-109 compliant equipment
- Standard industrial PLC and automation controller sensor inputs
