Overview
The Allen-Bradley 800T-NX1540 is a 30mm illuminated red pushbutton operator engineered for heavy-duty industrial control applications. Part of the proven Bulletin 800T line, this Series T operator combines durable construction with the visibility benefits of red illumination for critical manual control and emergency stop applications. The robust design delivers consistent performance in Type 4/13 (watertight/oiltight) environments and provides exceptional mechanical reliability for thousands of operating cycles.
Key Features
- 30mm size with industry-standard mounting footprint for easy integration
- Illuminated red operator for clear visual indication and status monitoring
- Series T designation offers proven reliability in demanding industrial settings
- Type 4/13 watertight and oiltight rated construction
- Compatible with wide range of contact blocks and control accessories
- Superior lens cap design with optical enhancements for consistent illumination
Technical Specifications
The 800T-NX1540 maintains compatibility with standard 30mm mounting holes and pairs with Allen-Bradley contact blocks rated for both pilot-duty and higher-current applications. The illuminated red design utilizes molded lens technology for breakage resistance and superior material durability. Mechanical operation rating exceeds 150,000 cycles when paired with self-monitoring contact blocks (SMCBs) for enhanced e-stop reliability.
Typical Applications
- Emergency stop (E-stop) pushbutton stations
- Manual motor start/stop control circuits
- Industrial machine safety interlocks
- Plant floor equipment control panels
- Watertight control enclosures and hazardous location stations
Compatibility & Replacements
