Overview
The Allen-Bradley 800T-FXNPL16GA7 illuminated pushbutton switch is a precision-built control component designed to deliver reliable operation in industrial environments. As part of the robust Series T line, this 30mm unit combines proven mechanical durability with illuminated operation to enhance operator visibility and safety. The 800T-FXNPL16GA7 is suitable for machinery control, process automation, and electrical panel applications requiring a dependable momentary or maintained switching action.
Key Features
- 30mm Form Factor: Industry-standard size compatible with most industrial panel layouts and enclosures
- Illuminated Operation: Built-in indication for enhanced visibility in low-light or demanding environments
- Durable Construction: Heavy-duty aluminum body and sealed contact blocks rated for harsh industrial conditions
- Series T Design: Proven performance characteristics backed by decades of industrial use
- Multiple Contact Options: Compatible with standard N.O. (normally open) and N.C. (normally closed) contact blocks for flexible control logic
Technical Specifications
- Button Size: 30mm
- Mounting Style: Panel-mount with bottom conduit entry
- Material: Aluminum construction
- Operating Temperature: –20 °C to +60 °C (without moisture or liquids)
- Electrical Lifecycle: 1,000,000+ minimum operations
- Maximum Continuous Current (Standard Contacts): 5 A AC/DC
- Contact Types Supported: Standard, sealed, and self-monitoring contact blocks
- Series Designation: 800T (Series T)
Typical Applications
- Manufacturing equipment start/stop control
- Pump and motor control stations
- Industrial automation panel interfaces
- Process control operator stations
- Machine safety and emergency stop circuits
- HVAC and utility equipment control
Compatibility & Replacements
Compatible With
- Allen-Bradley 800T-series contact blocks and operator assemblies
- Standard 30mm industrial pushbutton enclosures
- Panel-mount control systems using ½-inch NPT conduit entry
- Industrial control circuits rated for 5 A AC/DC maximum
- Sealed and explosion-protected control applications (when used with appropriate contact blocks)
Replaces / Drop-In Replacement For
- Earlier generation Allen-Bradley 800T illuminated pushbutton models with equivalent 30mm mounting
- Verify exact compatibility with your system integrator before ordering, as contact block configuration may differ
Works With
- Allen-Bradley contact blocks (N.O., N.C., and sealed variants)
- Standard industrial electrical enclosures and control panels
- Hardwired relay logic and PLC input circuits
- Emergency stop and safety control systems
- Both AC and DC control voltage supplies
