Overview
The Allen-Bradley 22F-D2P5N103 is a compact, cost-effective PowerFlex 4M variable frequency drive (VFD) designed for precise motor speed control in industrial automation. This Frame A drive combines reliable Rockwell/Allen-Bradley engineering with flexible programming options, making it ideal for OEM integrators, maintenance professionals, and control system designers.
Key Features
- Compact Frame A footprint with DIN rail and panel mounting support
- Integral LCD keypad with LED display for easy on-site configuration and diagnostics
- Drive overload protection and built-in ramp regulation for motor stability
- Flexible communication: DeviceNet, EtherNet/IP, MODBUS, and PROFIBUS support
- Fixed terminal block connections; feedthrough wiring capability
- Logix control platform integration for streamlined parameter and tag programming
Technical Specifications
- Power Rating: 0.75 kW (1 HP)
- Input Voltage: 340–528 VAC, 3-phase (480V nominal)
- Output Voltage: 0–460 VAC, 3-phase
- Output Current: 2.5 A
- Frequency: 50–60 Hz
- Frame Size: A
- Enclosure Rating: IP20 (Open), UL-NEMA Type Open
- Mounting: DIN rail or panel mount
- Connection Type: Fixed terminal block
- Serial Communications: RS-485 port
- Control Method: Volts/Hertz (V/Hz)
- Minimum Enclosure Volume: 1655 in³
- Display: LED with fixed digital keypad
- Brake Function: None
- CE Filter: Not included
Typical Applications
The 22F-D2P5N103 is suited for general-purpose industrial motor control including:
- Pump and fan speed control
- Conveyor and material handling systems
- HVAC equipment control
- Packaging and processing machinery
- OEM machine tool and automation equipment
- Production lines requiring variable speed motor operation
Compatibility & Replacements
Compatible With
- Allen-Bradley/Rockwell CompactLogix, ControlLogix, and Logix platforms
- Studio 5000 Logix Designer programming software
- EtherNet/IP, MODBUS, DeviceNet, and PROFIBUS networks
- Rockwell integrated architecture (consistent parameter structure across PowerFlex drives)
- DIN rail and panel-mounted control enclosures (Frame A standard mounting)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Contact Rockwell Automation Technical Support or your distributor for guidance on direct replacement models or firmware migration paths for legacy systems.
Works With
- Studio 5000 Logix Designer for parameter configuration and drive programming
- EtherNet/IP and MODBUS communication protocols
- Allen-Bradley remote and hand-held LCD keypads (optional accessories)
- External harmonic filters (available separately for advanced EMC requirements)
- Serial converter modules for DF1 port connectivity to legacy controllers
