Overview
The Allen-Bradley 2090-CHB1FS8-12AA25 is a feedback cable engineered for servo motor applications within the Kinetix motion control ecosystem. This cable assembly carries encoder signals from servo motors to compatible drives, ensuring accurate position and velocity feedback critical for closed-loop motion control systems. Built to Allen-Bradley’s 2090 series specifications, it meets industrial reliability and safety standards.
Key Features
- Dedicated feedback conductor design for encoder signal integrity
- CHB connector compatibility with standard Allen-Bradley servo motors
- 12-meter length pre-assembled and tested for immediate deployment
- Shielded construction to minimize EMI in high-noise factory environments
- Flexible jacket rated for dynamic cable routing and continuous-flex applications
- UL-approved for North American industrial installations
Technical Specifications
- Catalog Number: 2090-CHB1FS8-12AA25
- Cable Length: 12 meters
- Connector Type: CHB (servo motor feedback)
- Shielding: Foil and braid shield
- Jacket Material: PUR (polyurethane) or TPE, oil and abrasion resistant
- Operating Temperature: -20°C to +80°C
- Bend Radius (Continuous): 12× cable diameter
- Voltage Rating: 300V AC/DC
- Certifications: UL listed, CSA certified
- Standards Compliance: Allen-Bradley 2090 series
Typical Applications
This feedback cable is ideal for:
- Kinetix servo drive and TLP servo motor systems
- Robotic arm and gantry system feedback loops
- Conveyor indexing and synchronization control
- Machine tool spindle and axis positioning
- High-speed packaging and material handling equipment
Compatibility & Replacements
The 2090-CHB1FS8-12AA25 integrates seamlessly with Allen-Bradley’s Kinetix 5100, Kinetix 5300, and Kinetix 5500 servo drive families. It is compatible with TLP-series motors and other Kinetix-enabled servo motors featuring standard CHB feedback connectors. When replacing legacy cables, verify connector pinouts and encoder type (incremental or absolute) to ensure proper signal transmission. For custom lengths or connector configurations, Allen-Bradley offers alternative 2090-series feedback cable assemblies.
